Manual for ACS-AP-x
Uploaded: April 20, 2026, 8:11 p.m.
Manual Publish Date: 2015-10-15
The user interface comprises a Home view for monitoring signals, a Menu for accessing drive functions, an Options menu for settings and status checks, and a Help feature for context-sensitive information. Users can navigate using arrow keys and softkeys, with a navigation memory to backtrack steps. Basic operations include parameter adjustments, fault tracing, and viewing system information.
Troubleshooting and error codes
| Status icon | Animation | Drive status |
|---|---|---|
| - | Stopped | |
| ↗ | - | Stopped, start inhibited |
| ↗↺ | Blinking | Stopped, start command given but start inhibited |
| ↗↘ | Blinking | Faulted |
| ↗↖ | Blinking | Running, at reference, but the reference value is 0 |
| ↗↪ | Rotating | Running, not at reference |
| ↗↘ | Rotating | Running, at reference |
