Manual for ACS880-604
Uploaded: April 20, 2026, 7:59 p.m.
Manual Publish Date: 2019-09-30
This manual provides detailed information on the ACS880-604 3-phase brake units as modules. It covers the product overview, operating principle, and hardware description, including the brake chopper module, DC connection, and capacitor charging. It also details connectors, fiber optic connections, and provides an overview of the power and control connections. The manual includes cabinet construction guidelines, electrical installation procedures, control unit information, start-up procedures, and fault tracing. Maintenance, ordering information, technical data, and dimension drawings are also included.
Troubleshooting and error codes
| Fault | Cause | Remedy |
|---|---|---|
| Overcurrent | Motor current too high. | Reduce the load or increase the motor size. Check motor and cable for faults. |
| Overtemperature | Brake resistor temperature too high. | Ensure adequate ventilation. Check brake resistor connection and size. Reduce braking duty. |
| Communication error | Loss of communication between control unit and module. | Check fiber optic cables. Restart the control unit and module. |
| DC link overvoltage | Excessive braking energy. | Check brake resistor size and connection. Ensure proper braking control. |
