Manual for FPBA-01
Uploaded: April 20, 2026, 8:03 p.m.
Manual Publish Date: 2017-01-25
Warranty Information
ABB provides a warranty for this product. Refer to the product documentation for details.
This manual provides information on installing, commissioning, and using the FPBA-01 PROFIBUS DP adapter module. It covers safety instructions, overview of the PROFIBUS network, mechanical and electrical installation, start-up procedures, communication profiles, communication protocol, diagnostics, technical data, and appendices with PROFIdrive parameters and I&M records. It is intended for users with basic knowledge of fieldbus interfaces, electrical fundamentals, and drive operation.
Troubleshooting and error codes
| LED | Indication | Possible Cause | Remedy |
|---|---|---|---|
| None | No LEDs lit | Module not powered | Check power supply connection. |
| MS | Flashing | Module in reset or boot mode | Wait until module is ready. |
| MS | On | Module operational | None |
| NS | Flashing | Initialization or self-test in progress | Wait until module is ready. |
| NS | On | Module operational, no communication | Check PROFIBUS cable connection, termination, and master configuration. |
| NS | Off | No communication | Check PROFIBUS cable connection, termination, and master configuration. |
