Brand: AEG
Category: Cooktop
Document Type: Manual
Language: EN
Manual for CCE84543FB
Uploaded: April 20, 2026, 7:48 p.m.
Warranty Information
Refer to the guarantee booklet for warranty period and authorized service center information.
- Activating and deactivating: Press and hold the On/Off button to activate or deactivate the hob.
- Using cooking zones: Place cookware in the center of the selected zone. Select the desired heat setting on the control bar. Press '0' to deactivate a cooking zone.
- PowerBoost: Touch 'P' to activate this function for increased power for a limited time.
- OptiHeat Control: Indicates residual heat on cooking zones.
- Timer: Use the timer to set operation time for cooking zones or as a minute minder.
- Hood functions: Activate/deactivate the hood, adjust fan speed, use AUTO mode for automatic adjustment, or Boost for maximum speed.
- Safety features: Child Safety Device and Lock prevent accidental operation.
Troubleshooting and error codes
| Problem | Possible cause | Remedy |
|---|---|---|
| You cannot activate or operate the hob. | The hob is not connected to an electrical supply or it is connected incorrectly. | Check if the hob is correctly connected to the electrical supply. |
| The fuse is blown. | Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. | |
| You did not set the heat setting for 60 seconds. | Activate the hob again and set the heat setting in less than 60 seconds. | |
| You touched 2 or more sensor fields at the same time. | Touch only one sensor field. | |
| Pause operates. | Refer to "Pause". | |
| There is water or fat stains on the control panel. | Clean the control panel. | |
| You can hear a constant beep noise. | The electrical connection is incorrect. | Disconnect the hob from the electrical supply. Ask a qualified electrician to check the installation. |
| You cannot select the maximum heat setting for one of the cooking zones. | The other zones consume the maximum available power. Your hob works properly. | Reduce the heat setting of the other cooking zones connected to the same phase. Refer to "Power management". |
| An acoustic signal sounds and the hob deactivates. | You put something on one or more sensor fields. | Remove the object from the sensor fields. |
| An acoustic signal sounds when the hob is deactivated. | You put something on the sensor field. | Remove the object from the sensor fields. |
| Residual heat indicator does not come on. | The zone is not hot because it operated only for a short time or the sensor is damaged. | If the zone operated sufficiently long to be hot, speak to an Authorised Service Centre. |
| The control panel becomes hot to the touch. | The cookware is too large or you put it too close to the control panel. | Put large cookware on the rear zones, if possible. |
| There is no sound when you touch the panel sensor fields. | The sounds are deactivated. | Activate the sounds. Refer to "Daily use". |
| The indicator above the symbol ⌖ comes on. | Child Safety Device or Lock operates. | Refer to "Child Safety Device" and "Lock". |
| The control bar blinks. | There is no cookware on the zone or the zone is not fully covered. | Put cookware on the zone so that it fully covers the cooking zone. |
| The cookware is unsuitable. | Use cookware suitable for induction hobs. Refer to "Hints and tips". | |
| The diameter of the bottom of the cookware is too small for the zone. | Use cookware with correct dimensions. Refer to "Technical data". | |
| The hood does not start or turns off. The indicators above the hood control symbols might also blink. | The fan may turn off by itself in certain conditions, e.g. when the room is not properly ventilated. | Open the window. You may need to install the window switch. Refer to "Assembly". If the window switch is already present, make sure it was correctly installed. Refer to the installation booklet. |
| Press any symbol. The hood operates again. | ||
| The hood fan does not work properly when the hood functions are activated. | The ambient temperature surrounding the hood is too high. There is insufficient air circulation inside and around the hood. | Deactivate the hob and unplug it from the main power supply. Wait at least 10 seconds, then plug it in again. Other suggestions: Try to cool down the temperature of the surrounding area. Take out the hood filter and remove the residual moisture from the inside of the hood. Refer to "Care and cleaning". Leave the hood system to dry for one day, then activate the hood again. |
| The steam produced during cooking is not sufficiently absorbed by the hood. | The lids on the cookware are not properly placed. | If your cookware does not have vented lids, make sure to tilt the lids so that the released steam is directed towards the hood. Refer to "Hints and Tips" for information on the special Steam Vented Lids recommended to be used with the integrated hood. |
| The hood filter is oversaturated. | Regenerate the hood filter and reset the notification. Refer to "Care and cleaning". |
