Introducing your Computer:

  • Unpacking: Details what to expect in the box, including the system unit, power cords, and documentation. Advises keeping packaging for transport and noting manufacturer data for service needs.
  • Energy-efficient features: Complies with "Energy Star" program, supporting System Management Mode (SMM) and Advanced Power Management (APM). Features VESA BIOS Extensions for monitors supporting DPMS.

Getting Started:

  • General advice: Recommends siting the computer in a stable, dry environment away from extremes of temperature and sunlight. Emphasizes ergonomic considerations for monitor and keyboard placement and ensuring adequate ventilation.
  • Connecting the components: Provides a step-by-step guide to connecting the system unit, monitor, keyboard, mouse, and peripherals. Stresses the importance of connecting in the correct order and ensuring power is off.
  • Turning on and booting the computer: Explains how to power on the system using the POWER button, the function of the power indicator, and the power-on self-test (POST). Describes the boot sequence, looking for a system diskette or booting from the hard disk.
  • Starting the computer for the first time: Mentions a legal message regarding software use that requires user acknowledgement.
  • Why your computer may seem to stop working: Explains the energy-saving standby mode where the screen may blank and the processor slows down, which is reactivated by keyboard or mouse input.
  • Turning the power off: Outlines a checklist before shutting down, including saving files, logging out of networks, closing software, and turning off peripherals first. Details the power-off procedure via the POWER button.

Using your Computer:

  • Using the 3.5" diskette drive: Describes the drive's capacity (720 Kbytes and 1.44 Mbytes), how to insert and remove diskettes, and the importance of write-protection.
  • Using the CD-ROM drive: Explains its capability to retrieve data from CD-ROMs and play audio CDs. Notes the dependence on operating environment software and the importance of not moving the computer while a CD is in use.

Troubleshooting and error codes

Code Cause Code Cause
0 Keyboard locked 301 Keyboard data line failure
101 Timer tick interrupt failure 301 Keyboard stuck key failure
102 Timer 2 test failure 303 Keyboard controller failure
106 Diskette controller failure 604 Diskette drive 0 failure
110 System board memory parity interrupt 604 Diskette drive 1 failure
114 Option ROM checksum failure 605 Diskette unlocked problem
151 Real time clock failure 662 Diskette drive configuration
161 Real time clock battery failure 762 Coprocessor configuration
162 CMOS RAM checksum failure 962 Parallel configuration
162 Invalid configuration information 1162 Serial configuration
163 Time of day not set -preboot 1762 Hard disk configuration
164 Memory size does not match CMOS 1780 Fixed disk 0 failure
165 Add/remove MC card 1781 Fixed disk 1 failure
166 Memory configuration change 1782 Fixed disk 2 failure
175 Bad EEPROM CRC #1 1783 Fixed disk 3 failure
176 System tampered 1800 No more IRQ available
177 Bad PAP checksum 1801 No more room for option ROM
178 EEPROM is not functional 1802 No more I/O space available
183 PAP update required 1803 No more memory <1Mb available
184 Bad POP checksum 1804 No more memory >1MB available
185 Corrupted Boot sequence 1805 Checksum error or 0 size option ROM
186 Hardware problem 1806 PCI-PCI bridge error
187 VPD S/N not set 1962 No bootable device
188 Bad EEPROM CRC #2 2400 Display adapter failed; using alternate
189 Excessive password attempts 2462 Video configuration
201 Base memory error 5962 IDE CD-ROM configuration
229 External cache failure 8601 Pointer device failure
301 Keyboard failure 8603 Pointer device has been removed
301 Keyboard clock line failure
