Warranty Information

Asahi Pentax cameras are guaranteed against manufacturing defects for one year from the date of purchase.

How to Hold Your Camera

  • Horizontal Position: Hold the camera firmly with your left hand, arm close to your body.
  • Vertical Position A: Hold camera tightly to forehead with left hand, right arm close to body.
  • Vertical Position B: Hold camera tightly to forehead with left hand, raise right arm, draw left arm to body.
  • Hold the lens barrel with your left hand's thumb and fingers when focusing horizontally.
  • Use the right hand to release the shutter to avoid camera movement.

Before Taking Pictures

  1. Set preview lever to 'A' (automatic) for full-aperture viewing.
  2. Cock rapid wind lever fully.
  3. Select desired f-stop.
  4. Set shutter speed.
  5. Compose through viewfinder.
  6. Focus using the distance scale ring.
  7. Trip shutter.
  8. For depth of field, switch preview lever to 'M' (manual).

Film Loading

  1. Open camera back by pulling lock.
  2. Pull out rewind knob, insert cassette, push knob back.
  3. Draw film leader and insert into take-up spool slit.
  4. Turn wind lever to engage sprockets with film perforations.
  5. Close back and fasten lock.

Troubleshooting and error codes

ProblemPossible CauseSolution
Shutter performance affected by temperatureExtremely hot or cold temperaturesKeep camera cool in hot weather; keep camera warm in cold weather. Avoid glove compartment or rear window sill of car.
Blurry picturesCamera movementHold camera firmly with left hand; avoid holding camera with the right hand when releasing shutter. Use a tripod for slow speeds.
Diaphragm not working correctly with Auto-Takumar 55mm f/1.8 lensLens number smaller than 462500Do not use this lens with SV and Sla camera bodies.
Film advance issueFilm not loaded properlyEnsure film is loaded correctly and wind lever is fully cocked.
Exposure errorsIncorrect exposure settingsUse the light meter; practice different exposure methods. Ensure correct ASA setting.
