Brand: BOSCH
Category: Dryer
Document Type: Manual
Language: EN
Manual for WTB86201UC
Uploaded: Nov. 21, 2025, 6:35 p.m.
Manual Publish Date: 2012-01-01
Warranty Information
Bosch warrants the Product to be free from defects in materials and workmanship for 365 days from the date of purchase.
Operating Your Dryer
To operate your Bosch dryer, follow these steps:
- Load Laundry: Ensure the lint filter is clean. Load laundry into the drum, making sure not to overfill. Close the door securely until it clicks.
- Select Program: Rotate the program selector to choose the desired drying program based on your laundry type and desired dryness. Consult the program selection table for guidance.
- Adjust Settings (Optional): You can select additional options like Low Heat or Wrinkle Block if needed.
- Start Cycle: Press the Start/Pause button. The indicator lamp will light up, and the cycle will begin. The display will show the estimated remaining time.
- Monitor Cycle: The dryer uses sensors to monitor moisture and will end the cycle automatically when the selected dryness level is reached. The drum may rotate periodically to prevent creasing.
- Remove Laundry: Once the program ends, open the door, remove the laundry, and turn the program selector to Off. Clean the lint filter after each use.
Refer to the manual for detailed instructions on program selection, options, and maintenance.
Troubleshooting and error codes
| Problem | Possible cause(s) | Solution(s) |
|---|---|---|
| Dryer does not start. Start/Pause indicator light does not illuminate. | Main plug not inserted at all or not inserted correctly. | Insert main plug correctly. |
| A fuse of power supply is tripped. | Replace/switch on fuse. | |
| Start/Pause button not pressed. | Press Start/Pause button. | |
| Door not closed properly. | Check if laundry is caught in the door, address the issue. Close the door until a click is heard. | |
| Ambient temperature below 41°F/5°C. | Increase room temperature. | |
| Program not selected. | Rotate the program selector to desired program. → Program selection table; Page 20 | |
| The display panel lighting and indicator lights go out, Start/Pause indicator light flashes. | Energy-saving mode is activated. | Press any button to activate the lighting. → Environmentally friendly use of your dryer; Page 7 |
| The display panel switches off. | Sleep mode after setting the Finished in option is activated. | Press any button to activate the lighting. |
| The Cleaning req. indicator light up. | Lint filter dirty. | Clean lint filter. → Cleaning the lint filter; Page 27 Press the Start/Pause button to reset the displayed indication and then press Start/Pause button again to reset the appliance if necessary. |
| Heat exchanger dirty. | Clean heat exchanger. → Cleaning the heat exchanger; Page 28 Press the Start/Pause button to reset the displayed indication and then press Start/Pause button again to reset the appliance if necessary. | |
| The Check drain indicator light up. Water has not drained completely. | Drain hose is blocked. | Check drain hose. → Maintenance of drain hose; Page 29 |
| Drain hose is leaking: is not screwed on the tight at both ends, or rubber not placed in hose. | Check drain hose connection conditions. | |
| Water is leaking out. | Dryer is not leveled. | Level the dryer. → Leveling the dryer; Page 14 |
| The heat exchanger seal is dirty. | Clean the heat exchanger seal. → Cleaning the heat exchanger; Page 28 | |
| Program terminates shortly after starting. | Ambient temperature greater than 41°F/5°C. | Ventilate the room. |
| Laundry is not loaded. | Load the laundry. → Loading the laundry; Page 25 | |
| Load too small for selected program. | Use time program. → Program selection table; Page 20 | |
| Loaded laundry dry. | Check the loaded laundry. If it is dry, open the door, remove laundry and turn program selector to Off. | |
| The door opens by itself. | The door not closed properly. | Close the door until a click is heard. |
| Creasing. | Laundry load exceeded. | Do not exceed the maximum load for selected program. Remove items of laundry immediately after the end of the program, hang them up and pull into shape. Turn program selector to Off. → Program selection table; Page 20 |
| Unsuitable program selected. | Use another drying program or, in addition, select the time program. | |
| Drying result is not satisfactory (laundry feels too damp). | Warm laundry may feel damper than it really is. | Remove items of laundry immediately after the end of the program and turn the program selector to Off. |
| The selected program does not suit the load. | Use another drying program or, in addition, select the time program. → Program selection table; Page 20 | |
| Dryness level is not adjusted. | Use Dry Level to adjust the dryness level. → Dry Level; Page 21 | |
| Drying time too long. | Fine layer of limescale on the humidity sensors. | Clean the moisture sensors. → Cleaning the moisture sensors; Page 29 |
| Program termination e.g. main power supply failure, door open or maximum drying time reached. Laundry is too wet. | See the problem(s) mentioned in this table. | |
| Lint filter is dirty. | Clean lint filter. → Cleaning the lint filter; Page 27 | |
| Insufficient supply of air. Air inlet possibly blocked. Ambient temperature higher than 95°F/35°C. | Ensure that air can circulate. Do not obstruct the air inlet on the front of the dryer. Ventilate the room. | |
| Program does not start Finished in (remaining) time is displayed. | Program ending time has been selected and activated. | Drying cycle will begin at proper time to complete at the selected Finished in time. |
| Program does not start - symbol light up. | Childproof look is activated. | Deactivate Childproof look. → Childproof lock; Page 26 |
| One or more indicator lights are flashing. | Lint filter or/and heat exchanger is dirty. | Clean lint filter or/and heat exchanger (see solution of the problem(s) in this table above). |
| Installation conditions are not fine. | Check the installation conditions. → Electrical Connections; Page 13 | |
| Power failure. | Fault in program sequence or malfunction. | Switch off the dryer, allow it to cool down, switch back on and restart the program. Remove laundry from the dryer immediately and spread out. This allows the heat to dissipate. Be careful as the door, the drum and the laundry may be hot. |
