Manual for 6136/30M-101

Operation

Touch Screen

The screen reacts to touch. Use the supplied pen or finger to navigate. The functions are software-dependent and determined by the project. Pages can be programmed individually with 5 or 10 buttons or up to 8 icons.

Screen Safeguarding

To prevent unauthorized use, press the start page title for over 3 seconds. A lock symbol appears. The display is now safeguarded and can only be enabled by pressing long again. Recommended for public areas or as a child lock.

System Settings

Access basic settings via the 'System' button. Settings can be PIN-protected or blocked. Adjust date, time, display lighting, volume, contrast, and warning tones. Touch display adjustment may be needed if input is inaccurate.

Thermostat and Climate Control

The integrated room thermostat manages climate and temperature. Modes include Stand-by, Comfort, and Nighttime temperature reduction. It can also control external room thermostats for central temperature management.

Time Programmes

Control lighting, blinds, and heating via time schedules. Up to 20 units can be controlled at 5 or 10 different times per panel. Access can be PIN-protected.

Remote Control

Operate the system using Busch-Jaeger 6010-25 or Bang & Olufsen BEO4 (select models) infrared remote controls for functions like lamp control, scene management, and switching consumers off.

Installation and Software

Installation involves electric connections and mounting in a flush-mounting box. Software installation and programming can be done using ETS or Power-Projekt software, with options for SD/MMC card or bus programming.
