Brand: Canon
Category: Camera
Document Type: Manual
Language: EN
Manual for LEGRIAGF G60
Uploaded: Aug. 10, 2025, 12:30 a.m.
Manual Publish Date: 2019-03-01
Warranty Information
None
Highlights of the Camcorder
The Canon LEGRIA HF G60 4K Camcorder offers a compact design ideal for various situations. Key features include:
- 4K Recording: Equipped with a 1.0-type CMOS sensor and DIGIC DV 6 imaging platform for high sensitivity and low noise.
- Wide Zoom Lens: Features a 15x optical zoom lens with a 25.5 mm wide-angle capability.
- Convenience and Functionality: Versatile design, advanced image stabilization, manual controls (focus/zoom ring, customizable buttons), and dual SD card slots.
- Dual Pixel CMOS AF: Enhances autofocus performance, including face detection and tracking.
- Creativity and Artistic Expression: Supports special recording modes like slow/fast motion and custom "Looks" for picture adjustment.
Other features include battery compatibility with Intelligent System, GPS receiver compatibility, and remote controller compatibility.
Troubleshooting and error codes
| Issue | Solution |
|---|---|
| Camcorder fails to operate correctly | Refer to Troubleshooting (page 108) |
| ACCESS indicator is illuminated or flashing in red | Observe precautions: Do not disconnect power, open card compartment, change mode, or disconnect USB cable. Failure to do so may result in permanent data loss. |
| Battery charging issues (POWER/CHG indicator flashing) | Refer to Troubleshooting (page 109) |
| Remaining battery time inaccurate | Charge battery pack fully. May be inaccurate due to continuous use, high temperatures, long periods of disuse, or battery life. Use screen approximation. |
| Non-Canon battery packs | Will not charge; [ Battery communication error] message may appear. Canon is not liable for damages from non-genuine parts. |
| SD card data corruption/loss | Back up recordings. Avoid dust, dirt, magnetic fields, high humidity/temperature, physical shock, and water. Ensure correct insertion direction. Do not apply labels. |
| Built-in backup battery depleted | Recharge by connecting power adapter for 24 hours with camcorder off. |
| Lithium Button Battery Warning | Mishandling may cause fire/burn hazard. Do not disassemble, modify, heat, incinerate, swallow, recharge, short-circuit, or insert incorrectly. Keep away from children. Return used batteries for disposal. Do not handle with metal tools. Wipe with dry cloth. |
| Condensation | Stop use if detected. Do not expose to sudden temperature changes. Remove cards/battery, place in airtight bag to adjust gradually. Wait 2 hours before resuming use after condensation. |
