Parts/Service for imageRUNNER ADVANCE 6575i/6565i/6555i
Uploaded: Sept. 12, 2025, 4:19 a.m.
Manual Publish Date: February 2016
Warranty Information
90 days or 200,000 prints/copies, whichever comes first, for the product and its accessories.
The imageRUNNER ADVANCE 6500 Series devices offer high-speed, high-performance black-and-white digital imaging. They are designed for mid-high office environments and provide capabilities such as printing, copying, scanning, and faxing. Key features include a standard Single-Pass Duplexing Automatic Document Feeder, a 250 GB hard disk drive, a 10.1" color TFT touch screen, and Universal Send for digital data distribution. Various optional accessories and software solutions can be installed to enhance functionality. Security features include device authentication, data security, and network security. The devices are ENERGY STAR certified.
Troubleshooting and error codes
| Main Unit Periodic Maintenance | Remarks | |||||
|---|---|---|---|---|---|---|
| Part Name | 250,000 | 300,000 | 500,000 | 1,000,000 | As needed | |
| Dustproof Glass | Δ | Clean with lint-free paper moistened with alcohol. | ||||
| Grid Wire | Δ | Clean when Primary Charging Wire is replaced. Clean with lint-free paper moistened with alcohol. In a high temperature/ humidity environment (30 deg C/80%), the interval is 250,000 sheets. | ||||
| Primary Charging Assembly Shield Plate | Δ | |||||
| Pre-transfer Charging Assembly Shield Plate | Δ | |||||
| Drum Cleaning Unit Plate | Δ | Clean with lint-free paper moistened with alcohol. | ||||
| Pre-exposure Plastic Sheet | Δ | |||||
| Toner collection area | Δ | Crumb toner clusters. In a high temperature/ humidity environment (30 deg C/80%), he interval is 250,000 sheets. | ||||
| Separation Claw Mounting Base Process Unit Rear Guide | Δ | Clean with lint-free paper moistened with alcohol. | ||||
| Drum Sliding Assembly | Δ | × | Apply lubricant at the Drum Sliding Assembly when abnormal sound is heard at the time of operation (FY9-6008). | |||
