What you can do with your CASIO camera
Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions.
Shooting better looking portraits/ Beautiful images, even in dark locations
Make-up adjusts skin tone and texture to make your portraits look better. The effect of Make-up provides bright images even in dark locations.
→ See pages 41, 63 for more information.
Simple self-portrait shooting
The monitor screen can be rotated so it faces in the same direction as the camera's lens, making self-shooting much easier.
→ See page 47 for more information.
Comparison View
View two snapshots at the same time to compare them. You can also use this view to send images to a smartphone and to apply the make-up settings of an existing image to subsequent shooting.
→ See page 76 for more information.
Favorites
You can add images you like to your favorites.
→ See page 70 for more information.
Selfie Art
Apply different effects to make self-portraits shot better looking and more interesting.
→ See page 45 for more information.
Instant Movie
Movie recording can be paused and resumed as required to create a short movie quickly and easily.
→ See page 53 for more information.
Wireless Connection
Use EXILIM Auto Transfer to transfer images you shoot with the camera to a smartphone or a social networking service automatically. You can also turn your smartphone into a camera remote controller and send images recorded with your camera to your smartphone.
→ See page 83 for more information.
One Time Share
Share selected snapshots for viewing on smartphones that are not paired with the camera. The Scene app needs to be installed on the smartphone in order to use One Time Share.
→ See page 93 for more information.
Troubleshooting and error codes
| Power Supply | |
|---|---|
| Power does not turn on. | 1) The battery of new camera is not charged. Charge the battery before using the camera. 2) The camera battery may be dead. Charge the battery (page 19). If this does not resolve the problem, contact your retailer or a CASIO authorized service center. |
| The camera suddenly powers down. | 1) The camera is designed to turn off automatically after no operation is performed for about five minutes. Turn power back on. 2) The battery may be dead. Charge the battery (page 19). 3) The camera's protection function may have activated because camera temperature is too high. Turn off the camera and wait until it cools down before trying to use it again. |
| Power will not turn off. Nothing happens when a button is pressed. | Hold down the power button for at least 10 seconds to reset the camera. |
| Charging | |
| The operation lamp does not light red and the battery won't charge. | 1) Unplug the USB cable from the camera and then plug it back in again. 2) Make sure the camera is turned off when you connect the USB cable. Charging may not start if you connect the USB cable while power is turned on. |
| Image Recording | |
| Image is not recorded when the shutter button is pressed. | 1) If the camera is in the PLAY mode, touch "REC" to enter the REC mode. 2) If the message “Memory Full” appears, transfer images to your computer, delete images you no longer need, or use a different memory card. |
| Auto Focus does not focus properly. | 1) If the lens is dirty, clean it off. 2) The subject may not be in the center of the focus frame when you compose the image. 3) You may be moving the camera when shooting. Place the camera on a tabletop or some other stable surface, or find some way to fix the camera in place. 4) You may be pressing the shutter button all the way without waiting for Auto Focus. Half-press the shutter button and allow enough time for Auto Focus to focus. |
| The subject is out of focus in the recorded image. | The image may not be focused properly. When composing the image, make sure the subject is located inside the focus frame. |
| The LED light does not light. | 1) If the battery is dead, charge it (page 19). 2) LED light operation is disabled automatically whenever you are shooting with a BEST SHOT scene and HDR Art. Select a different recording mode (page 40). |
| Camera powers down during Self-timer countdown. | The battery may be dead. Charge the battery (page 19). |
| The monitor screen image is out of focus. | 1) You may be using "Macro" for scenery or portraits. Use Auto Focus for scenery and portrait shots (page 68). 2) You may be trying to use Auto Focus or "Infinity” when shooting a close-up shot. Use the "Macro" for close ups (page 68). |
| There is digital noise in images. | 1) Sensitivity may have been increased automatically for a dark subject, which increases the chance of digital noise. Use a light or some other means to illuminate the subject. 2) Shooting with a snapshot with a high ISO sensitivity setting can increase digital noise in the image. If digital noise becomes a problem, try changing the ISO sensitivity setting to a lower value. |
| A recorded image was not saved. | 1) Camera power may have been turned off before the save operation was complete, which will result in the image not being saved. If the battery indicator shows 2) You may have removed the memory card from the camera before the save operation was complete, which will result in the image not being saved. Do not remove the memory card before the save operation is complete. |
| Though available lighting is bright, the faces of people in the image are dark. | Not enough light is reaching the subjects. Adjust "Brightness" to the + side (page 65). |
| Night shots come out bad. | Use the "HS Night Scene" BEST SHOT scene (page 56) when shooting at night. |
| Shots in dark locations come out bad. | 1) Select "On" for the camera's “Lightness Priority" setting (page 63). This makes the overall subject bright, but you need to be careful of image blur due to camera movement. When using this function, shooting with a tripod or other means to secure the camera is recommended. 2) Select "Off" for the camera's "Lightness Priority" setting (page 63). 3) Use the LED light. |
| Subjects are too dark when shooting images in a seashore or ski area. | Sunlight reflected by water, sand, or snow, can cause underexposure of images. Adjust "Brightness” to the + side (page 65). |
| The image is out of focus during movie recording. | 1) Focusing may not be possible because the subject is outside the focus range. Shoot within the allowable range. 2) The lens may be dirty. Clean the lens (page 130). 3) During High Speed Movie recording, focus is fixed at the position where it was when recording started. To focus an image, half-press the shutter button for Auto Focus before you touch "" (Movie Start) to start recording. |
| I can't change the settings of menu items. Menu items for some settings are not displayed on the menu. | Some menu items may not be available, depending on the recording mode in use. While Premium Auto Pro is in use, only the menu items whose settings can be configured will be displayed on the menus. |
| Playback | |
| The color of the playback image is different from what appears on the monitor screen when shooting. | Sunlight or light from another source may be shining directly into the lens when you are shooting. Position the camera so sunlight does not shine directly into the lens. |
| Images are not displayed. | This camera cannot display non-DCF images recorded onto a memory card using another digital camera. |
| Images cannot be rotated. | Note that you cannot edit the following types of snapshots. • Snapshots recorded with another camera • Extracted subjects |
| File Deletion | |
| A file cannot be deleted. | The file may be protected. Unprotect the file (page 80). |
| Wireless Connection | |
| I can't establish a wireless connection. The wireless connection is broken. | 1) The camera cannot connect with a smartphone if they are too far apart from each other. 2) The smartphone may be connected with another wireless device. Check the smartphone's Wi-Fi settings and confirm that the camera is selected for wireless connection (page 89). 3) Connection may have been lost due to interference caused by a nearby microwave oven, cordless phone, or other wireless device. Move the camera away from the device causing the problem. |
| Location Information | |
| Location information isn't being added to my images. | 1) Pair the camera and smartphone, and then establish a Bluetooth wireless technology connection between them. 2) If you are shooting snapshots, select “On” for the camera's location information setting (page 101). 3) Configure smartphone settings to acquire location information, and make sure it is where location information can be received. |
| Other | |
| The wrong date and time are displayed, or the wrong date and time are being stored along with image data. | The date and time setting is off. Set the correct date and time (page 117). |
| The messages on the display are in the wrong language. | The wrong display language is selected. Change the display language setting (page 118). |
| Images cannot be transferred over a USB connection. | 1) The USB cable may not be connected securely. Check all connections. 2) If the camera is not turned on, turn it on. 3) Your computer may not be able to recognize the camera if you connect via a USB hub. Always connect directly to the computer's USB port. |
| Language selection screen appears when the camera is turned on. | 1) You did not configure initial settings after purchasing the camera or the camera may have been left with a dead battery. Check the camera setup (pages 25, 117). 2) There may be a problem with the camera's memory data. If this is the case, perform the reset operation to initialize the camera's setup (page 120). After that, configure each setting. If the language selection screen does not re-appear when you turn the camera on, it means that the camera's memory management data has been restored. If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. |
| There are various indicators and values on the monitor screen. | The monitor screen shows indicators and other information about shooting conditions and the image you are recording. You can disable display of indicators and values by selecting "Off" for "Info” on the Setup menu. |
| Buttons are not responsive right after the power has been turned on. | With large capacity memory cards there is a delay after the power has been turned on before the buttons become responsive. |
| Display Messages | |
| Battery is low. | Battery power is low. |
| Card ERROR | There is something wrong with the memory card. Turn off the camera, remove the memory card and then reload it into the camera. If this message re-appears when you turn the camera back on, format the memory card (page 119). • IMPORTANT! Formatting a memory card deletes all its files. Before formatting, try transferring recoverable files to a computer or some other storage device. |
| Communication stopped. | This message appears when the wireless LAN connection is broken for some reason during data communication between the camera and smartphone. |
| File could not be saved because battery is low. | Battery power is low, so an image file could not be saved. |
| Folder cannot be created. | You are trying to record a file while there are already 9999 files stored in the 999th folder. If you want to record more, delete files you no longer need (page 36). |
| LENS ERROR | This message appears and the camera turns off whenever lens performs some unexpected operation. If the same message appears after you turn power back on, contact a CASIO authorized service center or your original retailer. |
| Memory Full | Memory is full with images you recorded and/or files saved by editing operations. Delete files you no longer need (page 36). |
| Overheating. Power will turn off. | The camera's protection function may have activated because camera temperature is too high. Turn off the camera and wait until it cools down before trying to use it again. |
| Record Error | Image compression could not be performed for some reason during image data storage. Shoot the image again. |
| There are no files. | There are no files in built-in memory or on the memory card. |
| This card is not formatted. | The memory card loaded in the camera is not formatted. Format the memory card (page 119). |
| This function cannot be used. | This message will appear part way through an operation when you attempt to use a function that is not allowed in combination with another function. |
