Manual for QV-10

Manual for QV-10

Brand: CASIO

Category: Digital Camera

Document Type:

Language: EN

Uploaded: Aug. 9, 2025, 11:40 p.m.

Warranty Information

No specific warranty period is mentioned in the provided text.

Recording Images:
  1. Enter Record Mode (slide switch to REC).
  2. Turn on camera (slide POWER switch).
  3. Set NORMAL/MACRO switch to NORMAL.
  4. Compose image on LCD and press shutter button. Wait for "WAIT" message to clear before taking next picture.
Viewing Images:
  1. Enter Playback Mode (slide switch to PLAY).
  2. Turn on camera.
  3. Use [+] to go to next page, [-] to go to previous page.
Deleting Images:
  1. Enter Playback Mode.
  2. Scroll to the image to delete.
  3. Press DEL, then [+] to confirm single page delete, or [-] to select "DELETE ALL".
  4. Press shutter button to delete.
Connecting to Other Devices: Use VIDEO OUT terminal for TV/VCR/Video Printer and DIGITAL terminal for PC. Ensure power is off for all devices before connecting.

Troubleshooting and error codes

Symptom Probable Cause Action
No power 1. Batteries not loaded correctly. 1. Correctly load batteries (page 25).
2. Dead batteries 2. Replace batteries with new ones (page 25).
3. Wrong AC adaptor 3. Use only recommended AC adaptor (AD-C60).
Sudden power failure 1. Operation of Auto Power Off 1. Turn power back on.
2. Low battery power Use of manganese batteries 2. Replace batteries with new ones (page 25). Replace manganese batteries with alkaline batteries.
Low battery indicator on LCD Low battery power Replace batteries (page 25).
No recording when shutter button is pressed Function switch set to PLAY Set function switch to REC.
Power failure during self-timer operation Low battery power indicator Replace batteries (page 25).
Over exposure indicator on LCD Over exposure Change aperture switch setting to [] (page 42).
Under exposure indicator on LCD Under exposure Change aperture switch setting to [O] (page 42).
Poor LCD image focus Incorrect NORMAL/MACRO switch setting Use NORMAL for scenery and group photos, and MACRO for close-ups (page 40).
Poor color and brightness when indoors Indoor fluorescent lighting Shoot under incandescent or other non-fluorescent lighting (page 36).
Reflection from sunlight or other source 1. Reorient the camera so that light is not shining directly into lens.
Color of recorded image is strange. Difference between Record Mode and Playback Mode characteristics. This difference does not indicate a problem or malfunction.
No [+]/[-] button operation during multi-page display Button operation during page change Wait until an image is on the LCD before performing a button operation.
Cannot start auto play operation Only one image in memory Auto play can be used only when there are two or more images in camera memory.
All pages do not appear during auto play Auto play page range specification Change the auto play page range specification to include the pages you want to view.
Playback No display of image on connected TV screen 1. Function switch set to REC 1. Set the function switch to PLAY.
2. Incorrect connection 2. Use the special video cable that comes with the camera and connect correctly (page 51).
3. Wrong TV channel 3. Set the TV to the correct channel. See the TV's owner's manual for details.
Deletion Delete operation does not start when DEL is pressed 1. All pages are protected 1. Unprotect the page you want to delete (page 69).
2. Multi-page display (page 00) or zoom display (page 00) 2. Change to a normal-size, 1-page display format.
Other All buttons and switches do not operate Malfunction due to static electrical charge or strong impact Remove batteries and disconnect the AC adaptor if you are using one. Restore power and turn the camera on. If this does not work, contact your dealer or an authorized CASIO service provider.
Very bright or very dark LCD image Wrong BRIGHT setting Adjust the BRIGHT setting (page 16).
