Manual for 1090

Manual for 1090

Brand: Cecotec

Category: Robotic Vacuums

Document Type: Manual

Language: EN

Available Languages: ES , EN

Uploaded: April 20, 2026, 7:59 p.m.

Warranty Information

This product comes with a 2-year warranty from the date of purchase.

Quick Start Guide for Conga 1090 Series Robot Vacuum

  1. Preparation: Remove obstacles from the cleaning area. Place the charging base near a power outlet, ensuring 2 meters of clear space in front and 1 meter on each side.
  2. Assembly: Install the side brushes.
  3. Initial Charging: Place the robot on the charging base, ensuring terminals align. The robot will beep and the button will light up.
  4. Power On & Cleaning: Press and hold the power button to turn on the robot. Press the power button again or the AUTO button on the remote control to start cleaning.
  5. Cleaning Modes: Select from Auto-clean, Mop, Spot clean, and Edge clean modes.
  6. Scheduling: Use the remote control to schedule daily cleaning.
  7. Power Off: Press and hold the power button to turn off the robot.

Troubleshooting and error codes

Robot SignalCauseSolution
Solid red light1 beep: Omnidirectional wheel error.Clean the omnidirectional wheel and press the power button to restart the robot.
2 beeps: Side brushes error.Clean the side brushes and press the power button to restart the robot.
3 beeps: Motor fan or filter error.Remove and clean the dustbin. Remove the robot's filter and shake off the dirt.
4 beeps: Main brush error.Remove and clean the robot's main brush.
Flashing red light2 beeps: Bumper error.Check if the bumper is stuck and press both sides and the center to unblock it.
3 beeps: Anti-fall sensor error.Check if the robot is on an uneven surface, if the wheels are not touching the ground, or if it is stuck in a dark area and move it to a new position. Otherwise, clean the anti-fall sensor.
4 beeps: Robot cannot return to the charging base or its initial position.Ensure there are no obstacles in front of the charging base. Clean the charging terminals of both the robot and the charging base with a clean, soft, and dry cloth.
