Warranty Information

Refer to the warranty information provided by the manufacturer.

Operation

  1. Place the cooler in front of an open window or door for fresh air intake.
  2. Pour clean water into the opening at the back of the appliance. Maximum capacity is 13 liters, minimum for pump operation is 1.9 liters.
  3. Fill to the maximum fill level indicated inside the tank. Do not overfill.
  4. Refill with clean water when the water level is low.
  5. Ensure cross-ventilation by opening a door or window opposite the cooler.
  6. Plug the cooler into an electrical outlet and turn the power on.
  7. Turn the comfort control knob to the 'on' position.
  8. Turn the fan knob to the desired speed. Maximum cooling is achieved when the pad is saturated.
  9. If comfort level is not achieved, increase fan speed. Lower speeds are quieter.
  10. If the room becomes too cool or humid, turn the comfort knob off and/or turn the fan knob to a lower setting.
  11. Turn the cooler off by turning the fan knob to 'off'.

Troubleshooting and error codes

Condition Possible Cause Remedy
1. Appliance will not operate. 1.1 Power outlet or supply is faulty.
1.2 Wrong voltage.
1.3 Electrical fault. 		1.1.1 Check the power supply.
1.1.2 Check the power outlet.
1.2.1 Check that the power supply is the same as that specified on the appliance's rating label.
1.3.1 Electrical parts must only be repaired and replaced by Authorised Service Agents.
2. Appliance stops operating after running for some time. 2.1 Motor has overheated (safety cutout). 2.1.1 Wait 30-45 minutes for the motor to cool down. It should restart automatically. If this condition persists, take the cooler to a service agent.
3. No cooling. 3.1 Comfort control knob is off.
3.2 Tank is empty or nearly empty.
3.3 Pad and/or pump is blocked or dirty.
3.4 Pump is not working properly.
3.5 Pump drive belt faulty or broken 		3.1.1 Turn the comfort control knob to 'on'.
3.2.1 Fill the tank with water until the water reaches the maximum water level mark (13 litres).
3.3.1 Clean the parts. See Maintenance section.
3.4.1 The pump is not a separate electric pump. It is connected to the fan and motor and is driven mechanically. Turn the cooler off and drain the tank completely. Refill with clean water. Switch fan knob to high speed, turn the cool knob to 'on' and run the cooler for 10-15 minutes. This will help to flush out the dirt. The pad should now be wet. If the pad is not wet then the pump is still clogged and you should have the cooler checked by a service agent.
3.5.1 Replace the drive belt. See Maintenance section.
4. Appliance causes an unpleasant odor. 4.1 Tank or pad is dirty.
4.2 Water quality is poor. 		4.1.1 Drain the tank and fill the cooler with clean water. If the odor persists, clean run the cooler for 10-15 minutes then repeat the process. If the odor still persists, clean the tank and clean or replace the cooling pad.
4.2.1 Add vanilla essence or perfume to the water.
5. Appliance makes scraping or rattling noise. 5.1 Dirt has built-up in the pump. 5.1.1 Clean the parts. See Maintenance section.
5.1.2 Replace the drive belt. See Maintenance section.
6. Water overflows from the tank. 6.1 Too much water in the tank. 6.1.1 Drain some water out.
7. Damaged power supply cord. N/A 7.1.1 If the power supply cord is damaged it should be replaced by an authorised service agent.
8. Too much moisture or room is too cool. N/A 8.1.1 Reduce the fan speed and/or turn the water off. See Operation section.
