Manual for DSL-224

Manual for DSL-224

Brand: D-Link

Category: Networking

Document Type: Manual

Language: EN

Uploaded: Sept. 12, 2025, 4:24 a.m.

Manual Publish Date: 2020-07-07

Warranty Information

None

Safety Precaution

  • Use the power adapter in the package.
  • An overburden power outlet or damaged lines and plugs may cause electric shock or fire accident.
  • Proper space left for heat dissipation is necessary to avoid overheating.
  • Do not put this device close to a heat source or high temperature place.
  • Do not put this device close to over damp place.
  • Do not connect this device to PC or electronic product, unless instructed by a professional.
  • Do not place this device on an unstable surface or support.

Introduction

The DSL-224 supports multiple line modes and provides high-speed VDSL2(ADSL/ADSL2+) broadband connection to the Internet or Intranet. It supports both DSL uplink access and Ethernet uplink access with a downstream rate of 24 Mbps and an upstream rate of 1 Mbps.

Troubleshooting and error codes

Troubleshooting
1. How do I configure my DSL-224 Router without the CD-ROM?
Connect your PC to the Router using an Ethernet cable.
Open a web browser and enter the address http://10.0.0.2
The default username is 'admin' and the default password is 'admin'.
If you have changed the password and cannot remember it, you will need to reset the Router to the factory default setting (see question 2), which will set the password back to 'admin'.
2. How do I reset my Router to the factory default settings?
Ensure the Router is powered on.
Press and hold the reset button on the back of the device for approximately 15~20 seconds.
This process should take around 1 to 2 minutes.
Resetting the Router to the factory default settings will erase the current configuration settings.
3. What can I do if my Router is not working correctly?
Follow the directions in Question 2 to reset the Router.
Check that all the cables are firmly connected at both ends.
Check the LEDs on the front of the Router. The Power indicator should be on, the Status indicator should flash, and the DSL and LAN indicators should be on as well.
Please ensure that the settings in the Web-based configuration manager, e.g. ISP username and password, are the same as the settings that have been provided by your ISP.
4. Why can't I get an Internet connection?
For VDSL2(ADSL/ADSL2+) ISP users, please contact your ISP to make sure the service has been enabled/connected by your ISP and that your ISP username and password are correct.
5. What can I do if my Router can't be detected by running the installation CD?
Ensure the Router is powered on.
Check that all the cables are firmly connected at both ends and all LEDs are working correctly.
Ensure only one network interface card on your PC is activated.
Click on Start > Control Panel > Security Center to disable the firewall.
There is a potential security issue if the firewall is disabled on your PC. Please remember to turn it back on once you have finished the whole installation procedure. This will enable you to surf the Internet without any problems.
