Manual for DCS-2670L

Manual for DCS-2670L

Brand: D-Link

Category: Video Conferencing

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 9:12 p.m.

Manual Publish Date: 2017-06-01

Warranty Information

This manual does not contain explicit warranty period information.

  • Connect the camera to your network using an Ethernet cable and the power adapter.
  • Download and install the mydlink Lite mobile app on your smartphone or tablet.
  • Use the app to create an account or log in and follow the on-screen instructions to set up your camera.
  • For wireless setup, select Wi-Fi Setting in the app and follow the prompts to connect to your network.
  • Access the camera's web configuration utility via a web browser by entering its IP address to further configure settings such as image, audio, motion detection, and more.
  • The camera offers features like 180° wide-angle lens, 1080p Full HD video, IP65 weatherproof rating, and night vision.

Troubleshooting and error codes

Question Answer
What can I do if I forget the password for my camera's web configuration interface? Perform a factory reset by pressing and holding the RESET button for at least 10 seconds. This will revert all settings to factory defaults.
Why don't the LEDs light up? Check the power supply and connection. LEDs may also be disabled in the Admin settings.
Why is the camera's network connection unreliable? Check the network cable, hub/switch functionality, and wireless signal strength. Consider environmental factors affecting Wi-Fi range.
Why does a series of broad vertical white lines appear throughout the image? The image sensor might be overloaded by bright light. Reposition the camera to a shaded area. Prolonged exposure can damage the sensor.
The camera is producing noisy images. How can I solve the problem? Consider using night mode in low light environments.
The images are poor quality, how can I improve the image quality? Check image settings like brightness, contrast, and refer to Image Setup.
Why are no images available through the Web browser? Ensure ActiveX is enabled in Internet Explorer settings and that the latest version of Java is installed. Older IE versions may require upgrading.
