Brand: DEWALT
Category: Lawn Mower
Document Type: Manual
Language: EN
Manual for 12AVP2KL347
Uploaded: Sept. 12, 2025, 4:27 a.m.
Manual Publish Date: 2023-03-06
Warranty Information
MTD warrants the MTD Product will be free from defects in materials and workmanship for the specified Warranty Period.
Starting the Mower:
- Ensure the area is clear of debris.
- Check fuel and oil levels.
- Stand behind the mower, pull the recoil starter rope slowly until resistance is felt, then pull rapidly.
- Once the engine is running, squeeze the blade control against the upper handle.
- For self-propelled models, squeeze the drive control levers to engage the drive.
Stopping the Mower:
- Release the blade control to stop the engine and blade.
- Release drive control levers to stop self-propelling.
Adjusting Cutting Height:
- Pull the height adjustment lever outward.
- Move lever to the desired cutting height position.
- Release lever towards the deck.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Engine fails to start, runs erratic, overheats, skips, or idles poorly | Refer to the Engine Operator's Manual. | Refer to the Engine Operator's Manual for detailed troubleshooting. |
| Blade does not stop within 3 seconds after releasing the blade control | Safety interlock system malfunction or other internal issue. | Contact your Service Center. |
| Mower does not propel itself with the drive control engaged or wheels hesitate | Drive belt is loose or has issues. | Adjust the drive control wheel clockwise to tighten the cable. If necessary, contact an authorized Service Center. |
| Excessive vibration when rotating at high speeds | Unbalanced blade. | Check blade balance. Grind cutting edge equally to keep the blade balanced. Ensure the blade is properly installed and torqued. Contact Service Center if damage occurs. |
