Manual for RM 122F
Uploaded: Nov. 21, 2025, 6:38 p.m.
Operation Summary
This manual provides instructions for installing and operating Electrolux refrigerators, specifically models RM 123E and RM 122F. It covers installation requirements such as ventilation, leveling, and securing the unit, as well as changing door hinges and panels. The manual details electrical (12V and 230V) and gas connections, including wiring diagrams and safety precautions. It also explains how to start the refrigerator, regulate temperature, store food, make ice, and use the travel catch. Defrosting, cleaning, and maintenance procedures are outlined. A troubleshooting section helps diagnose common issues, and consumption figures for gas operation are provided.
Troubleshooting and error codes
| IF THE REFRIGERATOR FAILS TO WORK | Check the following points before calling a service technician: |
|---|---|
| 1. That the "STARTING THE REFRIGERATOR" instructions have been followed. | |
| 2. The refrigerator is level and not tilted in any direction. | |
| 3. If it is possible to start the refrigerator on any of the connected sources of energy. | |
| 4. If the refrigerator fails to work on gas, check | • That the gas bottle is not empty. • That all LP-gas valves are open. |
| 5. If the refrigerator fails to work on 12V, check | • That the 12V supply is connected to the refrigerator. • That the fuse on the 12V supply is intact. • That the 12V switch is on. |
| 6. If the refrigerator fails to work on 230V, check | • That the 230V supply is connected to the refrigerator. • That the fuse is intact. • That the thermostat is not switched to the 'off' position. |
| If the refrigerator is not cold enough it may be because: | |
|---|---|
| 1. | The ventilation is inadequate owing to objects such as wire mesh or winter covers blocking the ventilation passages. |
| 2. | The evaporator is frosted up. |
| 3. | The temperature control setting is incorrect. |
| 4. | The gas pressure is incorrect - check the pressure regulator at the gas container. |
| 5. | The ambient temperature is too high. |
| 6. | Too much food is loaded at the same time. |
| 7. | The door is not properly closed. |
| 8. | More than one source of energy is used at the same time. |
