Manual for EXI09HD1W
Uploaded: Nov. 21, 2025, 7:51 p.m.
Manual Publish Date: 2013-02-01
Warranty Information
This manual does not explicitly state the warranty period, but a typical period is assumed to be 24 months.
Basic Operation Summary:
This manual details the operation, specifications, installation, and troubleshooting of the Electrolux EXI09HD1W Air Conditioner. Key features include cooling, heating (for relevant models), dehumidifying, and fan-only modes. The unit offers various fan speeds (Auto, Low, Medium, High, Turbo) and swing functions for air distribution. Advanced features include an 'I Feel' function to sense room temperature at the remote control's location, an 'Eco' mode for energy-saving operation, and timer functions for setting start and stop times. The unit also incorporates self-cleaning (X-Fan) and sleep functions for enhanced comfort and convenience. Safety precautions and protection functions like overcurrent and antifreezing protection are detailed to ensure safe and reliable operation.
Troubleshooting and error codes
| Malfunction | Possible Cause | Remedy |
|---|---|---|
| Unit does not start | Power is not supplied. | Check power cord and fuse. |
| Indoor unit is turned off. | Turn on the unit with the remote control. | |
| Room temperature is within the operating range. | Wait for a while. | |
| Not cool/Not heat | Set temperature is not correct. | Set temperature correctly. |
| Air filter is dirty. | Clean the air filter. | |
| Indoor/Outdoor unit is blocked. | Check and clear obstructions. | |
| Door/window is open. | Close door/window. | |
| Thermostat is set to OFF. | Set thermostat to ON. | |
| Incorrect mode is selected. | Select the correct mode (Cool/Heat). | |
| Power failure. | Reset the unit. | |
| Communication fault. | Check wiring. Contact service if problem persists. | |
| Unit blows out hot air in cool mode / cold air in heat mode | Unit is not turned on for a sufficient time. | Wait for the unit to stabilize. |
| Defrosting operation is in progress. | Wait for defrosting to complete. | |
| Cold air prevention is active (in heating mode). | Wait for the unit to warm up. | |
| Water leakage | Drainage is blocked. | Clear the drain pipe. |
| Installation is not level. | Re-install the unit to be level. | |
| Ice build-up on indoor unit. | Ensure proper operation or contact service. | |
| Noise is too loud | Installation is not stable. | Secure the unit properly. |
| Foreign object inside the unit. | Remove foreign object. | |
| Fan is damaged. | Contact service. | |
| Abnormal operation/Error code | Refer to LED flashing indicators and fault diagnosis section. | Follow troubleshooting steps for specific error codes. |
