Warranty Information
Refer to the warranty card for detailed warranty information.
Operating Modes
- Cooling Mode: Provides cooling comfort.
- Dry Mode: Removes humidity from the air.
- Heating Mode: Provides heating comfort.
- Fan Only Mode: Circulates air without heating or cooling.
- Auto Mode: Automatically selects the operating mode based on temperature.
Key Functions
- Timer (Time-On & Time-Off): Allows setting automatic start and stop times.
- Sleep Mode: Gradually adjusts temperature for comfortable sleep.
- Turbo Button: Provides rapid cooling or heating.
- X-Fan Button: Keeps the fan running after shutdown to dry the unit.
- Vertical Louver Swing: Adjusts airflow direction vertically.
- Horizontal Louver Function: Adjusts airflow direction horizontally.
- ION Filter (Cold Plasma Function): Purifies the air.
- I FEEL Function: Senses room temperature for optimal comfort.
Troubleshooting and error codes
| Error Code | Description | Possible Cause | Solution |
|---|---|---|---|
| E1 | Indoor temperature sensor error | Sensor disconnection or short circuit | Check sensor connection and resistance. Replace sensor if faulty. |
| E2 | Outdoor temperature sensor error | Sensor disconnection or short circuit | Check sensor connection and resistance. Replace sensor if faulty. |
| E3 | Indoor/Outdoor communication error | Wiring issue between indoor and outdoor units | Check communication wiring. Replace if damaged. |
| E4 | Compressor overcurrent protection | Voltage issue, compressor fault, or faulty capacitor | Check power supply. Check compressor winding resistance. Replace capacitor if faulty. |
| E5 | Overload protection | Voltage issue or compressor fault | Check power supply. Check compressor. |
| E6 | Low pressure protection | Refrigerant leak or clogged filter | Check refrigerant level. Clean or replace filter. |
| E7 | High pressure protection | Dirty condenser, fan issue, or excessive refrigerant | Clean condenser. Check fan operation. Check refrigerant charge. |
