Warranty Information
Contact Electrolux for warranty information; always use original spare parts.
Basic Operation
This manual provides instructions for operating your Electrolux Air Conditioner.
Modes:
- Heating Mode: Requires exhaust hose. Set temperature and fan speed. Connect drain hose.
- Cooling Mode: Requires exhaust hose. Set temperature and fan speed. Drain hose not necessary.
- Fan Mode: No exhaust or drain hose needed. Select fan speed. Displays room temperature.
- Dry Mode: Exhaust hose not needed, but water collected must be discharged. Set mode, fan runs at low speed. Keep doors/windows closed. Connect drain hose.
- Auto Mode: Exhaust hose always attached. Unit automatically selects cooling, heating, or fan based on selected temperature and room temperature. Fan speed cannot be selected.
Other Functions:
- Filter Cleaning: Clean filter and reset indicator.
- Fan Speed Selection: Cycle through Auto Fan, High, Mid, Low. (Not available in Auto and Dry modes).
- Deactivate WiFi Module: Hold 'Connect' and '-' for 3 seconds.
Fault Codes:
- A5: Room temperature sensor failure.
- E5: Evaporator temperature sensor failure.
- E4: Display panel communication failure.
- P1: Bottom tray full. Drain unit.
- E7: Indoor motor failure.
Troubleshooting and error codes
| Warning | Meaning |
|---|---|
| Plug in power plug properly | Otherwise, it may cause electric shock or fire due to excess heat generation |
| Do not operate or stop the unit by inserting or pulling out Die power plug | It may cause electric shock or fire due to heat generation |
| Do not damage or use an unspecified power cord | It may cause electric shook or fire. If the power cord is damaged, it must be replaced by the manufacturer or an authorised service centre or a similarly qualified person in order to avoid a hazard |
| Do not modify power cord length or share the outlet with other appliances | It may cause electric shock or fire due to heat generation |
| Do not operate with wet hands or in damp environment | It may cause electric shock |
| Do not direct airflow at room occupants | This could harm your health |
| Always ensure effective earthing | Incorrect earthing may cause electric shock |
| Do not allow water to run into electric parts | It may cause failure of unit or electric shock |
| Always install circuit breaker and a dedicated power circuit | Incorrect installation may cause electric shock |
| Unplug the unit if strange sounds, smell, or smoke comes from it | It may cause fire and electric shock |
| Do not use the socket if it is loose or damaged | It may cause fire and electric shock |
| Do not open the unit during operation | It may cause fire and electric shock |
| Keep firearms away | It may cause fire |
| Do not use the power cord close to heating appliances | It may cause fire and electric shock |
| Do not use the power cord near flammable gas or combustibles, such as gasoline, benzene, thinner, etc. | It may cause an explosion or fire |
| Ventilate room before operating air conditioner if there is a gas leakage from another appliance | It may cause explosion, fire and burns |
| Do not disassemble or modify unit | It may cause failure and electric shock |
| Caution | Meaning |
|---|---|
| When the air filter is to be removed, do not touch the metal parts of the unit | It may cause an injury |
| Do not clean the air conditioner with water | Water may enter the unit and degrade the insulation. It may cause an electric shock |
| Ventilate the room well when used together with a stove, etc. | An oxygen shortage may occur |
| When the unit is to be cleaned, switch off, and turn off the circuit breaker | Do not clean unit when power is on as it may cause fire and electric shock, it may cause an injury |
| Do not place a pet or house plant where it will be exposed to direct air flow | This could injure the pet or plant |
| Do not use for special purposes | Do not use this air conditioner to preserve precision devices, food, pets, plants, and art objects. It may cause deterioration of quality, etc. |
| Stop operation and close the window in storm or cyclone | Operation with windows opened may cause wetting of indoor and soaking of household furniture |
| Hold the plug by the head of the power plug when taking it out | It may cause electric shock and damage |
| Turn off the main power switch when not using the unit for a long time | It may cause failure of product or fire |
| Do not place obstacles around air-inlets or inside of air-outlet | It may cause failure of appliance or accident |
| Always insert the filters securely. Clean filter once every two weeks | Operation without filters may cause failure |
| Do not use strong detergent such as wax or thinner - use a soft cloth | Appearance may be deteriorated due to change of product colour or scratching of its surface |
| Do not place heavy object on the power cord and ensure that the cord is not compressed | There is danger of fire or electric shock |
| Do not drink water drained from air conditioner | It contains contaminants and could make you sick |
| Use caution when unpacking and installing | Sharp edges could cause injury |
| If water enters the unit, turn the unit off at the power outlet and switch off the circuit breaker. Isolate supply by taking the power-plug out and contact a qualified service technician | It could cause electric shock and damage |
