Brand: ELECTROLUX
Category: Dishwasher
Document Type: Manual
Language: EN
Manual for ESL 4115
Uploaded: Nov. 21, 2025, 8:05 p.m.
Manual Publish Date: 2005-03-01
Warranty Information
Applies for 12 months from purchase for faulty workmanship or materials, provided the appliance is correctly installed and used.
Before First Use: Ensure water and electrical connections are correct, remove packaging, set water softener, fill salt container with 1 litre of water and dishwasher salt, and fill rinse aid dispenser. Adjust water softener manually and electronically if needed.
Daily Use: Check salt and rinse aid levels. Load dishes, ensuring spray arms can rotate freely and items don't obstruct each other. Add dishwasher detergent. Select and start a wash programme.
Loading: Do not wash sponges or cloths. Remove large food scraps. Load hollow items with openings downwards. Do not overload. Keep glasses from touching. Place small items in the cutlery basket.
Detergent: Use only dishwasher-specific detergents. Tablets go in the dispenser. Concentrated detergents are best with 50°C programmes. Combi detergents with rinse aid function require an empty rinse aid dispenser.
Programmes: Select the appropriate programme based on soil level and type of load.
End of Cycle: The dishwasher stops automatically with an audible signal. Open the door slightly to allow dishes to cool and improve drying. Switch off the appliance.
Troubleshooting and error codes
| Fault code / malfunction | Possible cause | Solutions |
|---|---|---|
| Continuous flashing of the indicator light of the running programme | The water tap is blocked or furred with limescale. The water tap is turned off. The filter in the threaded hose fitting at the water inlet valve is blocked. The water inlet hose has not been correctly laid or it is bent or squashed. | Clean the water tap. Turn the water tap on. Clean the filter in the threaded hose fitting. Check the water inlet hose connection. |
| The machine does not fill with water. | The sink spigot is blocked. The water drain hose has not been correctly laid or it is bent or squashed. | Clean out the sink spigot. Check the water drain hose connection. |
| The dishwasher will not drain. | Anti-flood device is activated. | Close the water tap and contact your Service Force Centre. |
| The programme does not start | The dishwasher door has not been properly closed. The main plug is not plugged in. The fuse has blown in the household fuse box. | Close the door. Insert the mains plug. Replace the fuse. |
| There is a whistling noise during washing | The whistling is not a cause for concern. | Use a different brand of detergent. |
