The Selecta II Control parameter memory is divided into two areas: Area A (General user level) and Area B (Service technicians). Area A contains Groups 0 and 1 for setting time/temperature and reading counters. Group 2 provides access to Area B. Area B includes Groups 3-9 and Group A for advanced settings, logs, diagnostics, and program adjustments. The manual details safety rules, PCB description, operating panel functions, versions, connector functions, programming mode, and various error codes (E13-E22) with their analysis and resetting procedures. Specific sections cover changing factory settings, resetting new settings, and accessing different program groups for advanced configuration.
Troubleshooting and error codes
| Error Code | Error Description | Analysis | Resetting |
| E13 | Drying error, dryer connected to a payment system | Occurs when payment system requests longer drying time than allowed 90 minutes. Error is registered but not displayed. Analysis involves checking payment system setup and PCB connection. | None specified |
| E14 | Gas error | Ignition control fails to detect a flame. Error displayed after unsuccessful ignition attempts (varies by region). Analysis involves checking flame sensor, ignition spark, gas supply, and current. | Push gas reset button on circuit board. (Japan only: open/close door) |
| E15 | Air pressure switch or vacuum switch | Air pressure or vacuum switch does not shut within 12 seconds after fan start. Analysis involves checking underpressure, fan motor direction, and AC voltage. | Open/close door and press start button. |
| E16 | Pressostat or vacuum switch does not open | Vacuum switch/pressostat is already closed when attempting to start dryer. Analysis involves checking heat setting, AC voltage, and harness. | Open/close door and press start button. |
| E17 | Input sensor disconnected | Inlet PT100 sensor is disconnected. Analysis involves checking sensor/harness resistance and PCB interface. | Open/close door and press start button. |
| E18 | Output sensor disconnected | Outlet NTC sensor is disconnected. Analysis involves checking sensor/harness resistance and PCB interface. | Open/close door and press start button. |
| E19 | Option | Not in use! | Not applicable |
| E20 | CMIS out of operation | Dryer put out of order in CMIS program. | See separate manual. |
| E21 | CMIS | Dryer connected in CMIS system, PC does not communicate within 10 sec. Warning, dryer operates. Error displays first 10 starts. Analysis involves checking CMIS start, ELS Network connection, and ELS Network setup. | None specified |
| E22 | LM10 | Dryer connected in LM10 system, PC does not communicate within 90 sec. Error removed when communication re-established. Analysis involves checking LM10 start, ELS Network connection, and ELS Network setup. | None specified |
