The Automower
Troubleshooting and error codes
| Symptom | Cause | Action |
| Uneven mowing results | Automower works too few hours per day. | Increase the mowing time, see "2. Timer" on page 29. |
| Working area too large. | Try limiting the working area or extending the working time, see "2. Timer" on page 29. | |
| Dull blades. | Replace all the blades and screws so that the rotating parts are balanced. | |
| Long grass in relation to the set cutting height. | Increase the cutting height. At the beginning of the season you may need to mow the lawn the first time with a conventional lawn mower before the Automower is put to work. | |
| Accumulation of grass by the blade disc or around the motor shaft. | Check that the skid plate and blade disc rotate easily. If not, the skid plate and perhaps the blade disc must be removed and the grass and foreign objects removed. See "Cleaning" on page 48. | |
| Automower runs at the wrong time | The Automower clock needs to be set. | Set the clock, see "Time and date (4-5)" on page 42. |
| The start and stop times for mowing are incorrect. | Adjust the start and stop time settings for mowing, see "2. Timer" on page 29. | |
| The Automower vibrates | Unbalanced blade disc or damaged blades. | Inspect the blades and screws and replace them if necessary. |
| Automower runs, but the blade disc does not rotate | The Automower is looking for the charging station. | No action. The blade disc does not rotate when the mower is searching for the charging station. |
| The mower mows for shorter periods than usual between charges | Grass or a foreign object is blocking the blade disc or skid plate. | Dismantle and clean the skid plate and blade disc. |
| Both the mowing and charging times are shorter than usual | This behaviour is normal in high temperatures (gradually increasing above 25 C). | No action |
