Warranty Information
This appliance is warranted by Electrolux for 24 months from the date of purchase, covering defective parts and workmanship, with certain exclusions.
Quick Operation Guide:
1. Setting the Clock: Initially, set the time of day using the appropriate buttons for your timer type (2-button, 3-button, or CHEFLOGIC). This is crucial for operation.
2. Preheating: Recommended for most cooking and grilling functions. Select the desired function (e.g., "rapid heat", "bake", "fan forced") and set the temperature. The oven is preheated when the indicator light goes out.
3. Cooking: Select the oven function and desired temperature. For multifunction ovens, the cooking function must be selected first.
4. Using the Timer: You can set a cooking time, a finish time, or a delayed start time using the timer functions. The oven will automatically switch off when the cooking time elapses.
5. Grilling: Ensure the grill door is open for "Grill (Separate)" and "Half grill (Split grill)". "Grill (In oven)" and "Maxi Grill" can be used with the door closed. Preheat for best results.
6. Cleaning: Clean the oven and accessories regularly. Catalytic self-clean panels (if fitted) require specific cleaning procedures. Never use abrasive cleaners or scourers.
7. Troubleshooting: Refer to the "SOLVING PROBLEMS" section for common issues and their solutions before contacting service.
Troubleshooting and error codes
| Problem | Possible Cause |
|---|---|
| Oven or grill not working: | • Time of day not set. • Timer is in "AUTO" mode. (Refer to timer operating instructions) • Power not turned on. • Controls are incorrectly set. • Household fuse has blown or power supply is off. • Child-proof oven lock activated. (Refer to operating instructions). NOTE: If the household fuse continues to blow, call the Service Centre. |
| Oven light not working: | • Lamp blown or loose in socket. • Household fuse has blown. NOTE: If the household fuse continues to blow, call the Service Centre. |
| Oven not heating enough: | • Foil or trays on bottom of oven. |
| Timer flashing on display: | • Power failure or interruption. NOTE: Reset time of day and any cooking functions you were using. (Refer to TIMER operating instructions). |
| Unit smoking when first used: | • Protective oils being removed. |
| Condensation building up: | • Reduce amount of water used in cooking. (Some condensation is normal) |
| Door cannot be replaced after removal | • Stirrup not engaged properly. |
| Solid hotplates - discolour | • Discolouration of elements and trim rings is normal during use, caused by heat. |
