Brand: Electrolux
Category: Tumble Dryer
Document Type: Manual
Language: EN
Manual for T5190
Uploaded: Nov. 21, 2025, 9:24 p.m.
Manual Publish Date: 2013-03-08
Warranty Information
Please refer to the warranty card for specific warranty details.
Loading: Load goods according to recommendations, close the door, and ensure the filter is clean. Maximum load is 10.6 kg.
Starting the machine: Select program by turning the control knob. Automatic programs allow selection of drying triangle and dryness options. Time programs do not have options. Press the control knob/start button to begin. Time can be adjusted after starting for time programs.
Additional Functions: Access additional functions via a menu after starting. Options include stopping, pausing, changing programs, ending programs, viewing status and statistics, and changing drum speed (on specific models).
Program End: Empty the machine promptly to prevent wrinkles. The drum may rotate intermittently if not emptied. Clean the filter after each cycle.
Starting the machine: Select program by turning the control knob. Automatic programs allow selection of drying triangle and dryness options. Time programs do not have options. Press the control knob/start button to begin. Time can be adjusted after starting for time programs.
Additional Functions: Access additional functions via a menu after starting. Options include stopping, pausing, changing programs, ending programs, viewing status and statistics, and changing drum speed (on specific models).
Program End: Empty the machine promptly to prevent wrinkles. The drum may rotate intermittently if not emptied. Clean the filter after each cycle.
Troubleshooting and error codes
| Error code | Text | Cause/Action |
|---|---|---|
| 12:11 | DRYING ERROR WITH RMC PROGRAM | The longest permitted RMC time has been exceeded. (Applies only to machines with RMC). The machine is overfilled or the garment is too wet. |
| 12:12 | DRYING ERROR WITH AUTOSTOP PROGRAM | The longest permitted automatic stop time has been exceeded. (Applies only to machines with automatic stop). The machine is overfilled or the garment is too wet. |
| 20:1 | O.H. DRUM MOTOR | The motor is too hot. The machine will restart automatically when the temperature on the motor is OK (if the door has not been opened). |
