3 OPERATION

3.1 Induction cookware

3.1.1 Overview

  • All pots and pans with a ferromagnetic base are valid for induction.
  • Only containers that have a base where a magnet remains adhered can be used.
  • The induction system does not heat up other kinds of containers, and the power level indicator on the display will blink.
  • The minimum diameter of the container must likewise be taken into account.

3.1.2 Valid pots and pans

  • Enamelled steel pots and pans.
  • Cast iron pots and pans.
  • Iron pans.
  • Stainless steel pots and pans, as long as they have a special ferromagnetic base for induction.

3.1.3 Pots and pans not valid for induction

  • Non-ferromagnetic or non-metallic materials.
  • Aluminium pots and pans.
  • Copper pots and pans.
  • Brass pots and pans.
  • Standard stainless pots and pans.
  • Glass ("Pyrex") containers.
  • Earthenware pans.

3.2 Modification of the YL146/147/... TC alarm tones

The user can, in accordance with the instructions for use, connect or disconnect the alarm sounds of the cooktop. The warning or alarm lights are always connected.

Step Sound connection or disconnection
1 Connect the main switch of the cooktop.
2 Put all heating elements at level 3.
3 Disconnect the heating elements from right to left.
4 Press the main sensor and hold for more than 5 seconds.
5 After 4 seconds, a beep is heard.
6 The alarm sounds have now been activated or deactivated depending on the previous status.

Troubleshooting and error codes

Cause of the breakdown: appliance components Burners Solution
Error Description
F0 There is no communication between the TC and the ELIN 2 or 4 1. Disconnect the cooktop from the power grid.
2. Check the TC-ELIN connection
3. If the failure continues, replace the ELIN.
e0 ELIN failure: (a defective path, NTC of ELIN open or short-circuited, damaged electronic component...). 2 Replace the ELIN
e1 ELIN failure that affects one burner (problem in the components or electrical paths of the board that power only one burner). 1 Replace the ELIN
e2 Fan failure 4 or 2 1. Check the fan connection.
2. Check the fan.
3. Replace the right ELIN.
e3 NTC open 1 Replace the NTC
e4 NTC short-circuited 1 Replace the NTC
c1 Insufficient voltage error (<185 V) 4 or 2 Disconnect the cooktop from the power grid. The error disappears when the correct voltage is supplied.
c2 Inductor temperature failure 1 The cooktop has heated up excessively, and the appliance must be disconnected from the power grid. If the failure continues, allow to cool.
c3 Radiator temperature failure 1 The cooktop has heated up excessively, and it must be disconnected from the power grid. If the failure continues, allow to cool.
E Exceeded. The times depend on the power level and go from 1 to 10 hours.
"E" blinks alternately with the power level or the residual heat indicator when the corresponding sensor has been pressed for too long (> 5 seconds), thereby sounding the acoustic signal. When the "on" sensor is pressed for more than this time, "E" appears on all displays.It can occur due to liquids spilled over the sensor zone or due to an object that has been left on top. The indicator disappears when the problem has been removed from the sensor and any other key is pressed.
F2 F and 2 blink alternately on the corresponding display if the NTC temperature of the TC is excessively high (> 100° C).If F2 appears, cooking zones 1 and 4 will not work.
F4 F and 4 blink alternately on the corresponding display if the NTC temperature of the TC is excessively high (> 100° C).If F4 appears, none of the 4 zones works.
ErXY The touch control has an internal failure (except with Er32).
Er32 This warning occurs when a touch control of a 21 appliance is connected to a 41 appliance, or vice versa. Check the replacement part.
cl The power grid voltage is too low.
U400 U400 appears static on the display and indicates an acoustic signal when the electronics have been connected erroneously at 400 V (This warning appears when the measured voltage on the power grids reaches 280 volts, and cases have occurred in which this warning appears at 250 volts). The electric company can divert the supplied voltage by +/- 7%.Disconnect the cooktop from the power grid. The failure disappears when the incorrect voltage is corrected.
F8 F and 8 blink alternately on the display corresponding to the cooking zone if the maximum cooking time has been

Mistakes with combination appliances
When the knobs are switched off, in touch control appear F0F0 without blinking. This mistake can be solved connecting the knobs properly.
On connecting the appliance, if the knob is not in zero position, a zero blinks in touch control depending on the knob.
