Parts/Service for L800/L801
Uploaded: Nov. 21, 2025, 6:32 p.m.
Manual Publish Date: 2011-04-06
Power-On Sequence
This section describes the power-on sequences, detailing the conditions and operations involved from turning on the printer to the final readiness state. It includes steps for checking waste ink overflow, avoiding deadlock, checking CDR tray sensor, releasing CR lock, seeking home position, resetting APG, initializing PF motor, and detecting ink cartridges.
Standard Operation Time
This section provides the standard operation time for servicing the product, broken down by parts/units. It lists the time in seconds for replacement and adjustment, along with the total time required for each component.
Troubleshooting and error codes
| Error type | Error code | Error name | Possible cause | |
| DC motor error | CR PID excess speed error | 01H | CR Encoder failure (contaminated/detached scale, Encoder Board failure) Motor driver failure (Main Board failure) Carriage overload (paper jam/foreign object) Cable disconnection |
|
| CR load positioning lock error | 02H | CR Encoder failure (contaminated/detached scale, Encoder Board failure) CR Motor failure Carriage overload (paper jam/foreign object) Cable disconnection |
||
| CR PID reverse error | 08H | CR Encoder failure (contaminated/detached scale, Encoder Board failure) Tooth skip of the CR Timing Belt Improper tension of the CR Timing Belt Carriage overload (paper jam/foreign object) |
||
| CR load positioning cumulative movement distance error | 0AH | CR Motor failure Motor driver failure (Main Board failure) |
||
| CR load positioning excess speed error | 0BH | CR Encoder failure (contaminated/detached scale, Encoder Board failure) Motor driver failure (Main Board failure) Carriage overload (paper jam/foreign object) Cable disconnection |
||
| DC motor error | CR PID lock error | 0CH | CR Encoder failure (contaminated/detached scale, Encoder Board failure) CR Motor failure Carriage overload (paper jam/foreign object) Cable disconnection |
|
| DC motor error | CR PID aveTi max error | 0DH | CR Motor failure Motor driver failure (Main Board failure) Improper tension of the CR Timing Belt Carriage overload (paper jam/foreign object) |
|
| PF Motor failure | PF PID acceleration lock error | FBH | PF Motor failure PF drive mechanism overload (paper jam/foreign object) |
|
| PF PID excess speed error | FEH | PF Encoder failure (contaminated/detached scale, Encoder Board failure) Motor driver failure (Main Board failure) |
||
| PF BS excess speed error | FCH | PF drive mechanism overload (paper jam/foreign object) Cable disconnection |
||
| PF excess measurement error | FAH | PF drive mechanism overload (paper jam/foreign object) | ||
| PF BS control positioning error | EFH | PF Motor failure Motor driver failure (Main Board failure) |
||
| PF BS control DTY max error | F0H | PF Motor failure PF drive mechanism overload (paper jam/foreign object) |
||
| APG motor | APG error (normal drive error) | 70H | Foreign object APG Unit failure (incorrect reassembling) |
|
| APG home position seeking error | 71H | APG Sensor failure Cable disconnection |
||
| APG drive error (by command) | 72H | |||
| Motor drive time error | CR (PID) driving time error | D1H | ||
| CR (load positioning) driving time error | D2H | Main Board failure | ||
| PF (PID) driving time error | D3H | |||
| PF (BS) driving time error | D4H | |||
| Command error | EEPROM verify error (by command) | 30H | ...* | |
| Printhead system error | Transistor temperature error | 40H | Main Board failure | |
| X-Hot detection error (before printing) | 41H | Printhead failure Main Board failure |
||
| X-Hot detection error (before flushing) | 42H | Printhead failure Main Board failure |
||
| Printhead system error | Head temperature error | 43H | Paper jam | |
| Sequence error | Home position seeking error | 50H | Foreign object | |
| CR lock release error | 51H | Deformation of the frame | ||
| CR lock error | 52H | |||
| Card error (before initial ink charge) | 53H | Foreign object | ||
| Impossible contact error (at powering off) | 56H | ___* | ...* | |
| Sensor error | PW sensor error (Hi check error) | 60H | PW Sensor failure Main Board failure |
|
| PW sensor error (Low check error) | 61H | PW Sensor failure Main Board failure |
||
| Sensor error | Tray sensor error | 62H | CDR Tray Sensor failure Main Board failure |
|
| Sensor error | PE sensor error | 63H | PE Sensor failure PE Sensor Lever failure Main Board failure |
|
| Maintenance error | Waste ink overflow | A0H | The maintenance counter has reached a limit. (Waste Ink Tray or Waste Ink Pad Lower) CDR Tray Sensor failure Main Board failure |
|
| Tray insertion error (during cleaning) | 88H | Paper jam Foreign object |
||
| Abnormal operation | Impossible contact error (during cleaning) | 89H | PF Motor failure Deformation of the frame PF drive mechanism overload (paper jam/foreign object) |
|
