Brand: EPSON
Category: Scanner
Document Type: Manual
Language: EN
Manual for DS-570W II
Uploaded: Nov. 21, 2025, 6:05 p.m.
Manual Publish Date: 2020
Warranty Information
Check your Pan-European Warranty Document for warranty information.
- Connect the scanner to a computer via USB or network.
- Load originals into the ADF (Automatic Document Feeder).
- Use the control panel buttons or accompanying software (Document Capture Pro, Epson Scan 2, Epson Smart Panel) to initiate scanning.
- Adjust settings such as resolution, color mode, and file format as needed.
- Scan documents, photographs, or cards.
- Utilize features like double-feed detection and paper protection for safe operation.
- Maintain the scanner by cleaning internal and external parts.
- Troubleshoot common issues using the provided guide.
- Configure network settings for wireless or wired connections.
Troubleshooting and error codes
| Problem | Page |
|---|---|
| Scanner Problems | 161 |
| Scanner Lights Indicate an Error | 161 |
| The Scanner Does Not Turn On | 161 |
| Problems Starting Scanning | 161 |
| Cannot Start Scanning from Computer | 161 |
| Cannot Start Scanning from Smart Device | 166 |
| Paper Feeding Problems | 169 |
| Multiple Originals Are Fed (Double Feed) | 169 |
| Removing Jammed Originals from the Scanner | 169 |
| The Original Jams in the Scanner Frequently | 171 |
| Paper Protection Does not Work Correctly | 171 |
| The Originals Get Dirty | 172 |
| Scanning Speed Slows Down when Scanning Continuously | 172 |
| Scanning Takes a Long Time | 172 |
| Scanned Image Problems | 172 |
| Straight Lines Appear when Scanning from ADF | 172 |
| Glass Dirt Alert Does Not Disappear | 173 |
| Colors Are Uneven in the Scanned Image | 173 |
| Expanding or Contracting the Scanned Image | 173 |
| Offset Appears in the Background of Images | 174 |
| Scanned Image or Text is Blurred | 174 |
| Moiré Patterns (Web-Like Shadows) Appear | 175 |
| The Edge of the Original is Not Scanned when Automatically Detecting the Size of the Original | 175 |
| Character is not Recognized Correctly | 176 |
| Cannot Solve Problems in the Scanned Image | 176 |
| Uninstalling and Installing Applications | 177 |
| Uninstalling Your Applications | 177 |
| Installing Your Applications | 178 |
