Manual for ES-C220/ES-C320W/RR-400W
Uploaded: Sept. 12, 2025, 4:30 a.m.
Product Basics
- Product Features: Includes scanning passports with straight path and optional carrier sheet, glass surface stain detection, and text enhancement for difficult-to-read originals.
- Document Protection: Scanner stops immediately upon detecting paper feed errors, angled originals, or mismatched original/scanner positions.
- Double-feed Detection: Option to stop scanning immediately or after the next document ejects upon detecting a double feed.
- Scan from Mobile: Use the Epson Smart Panel app to scan from iOS/Android devices, save, upload, or email scans.
Scanner Positions
- Vertical Path: For standard-size originals, thin paper, or receipts. Pull selector, tilt scanner forward. Originals ejected to the output tray at the top.
- Straight Path: For thick originals like passports. Pull selector, tilt scanner backward. Originals ejected to the output slot at the front.
Control Panel
- Buttons: Power, Stop, Start, Wi-Fi connect, Wi-Fi buttons (on ES-C320W/RR-400W). Combinations perform additional functions like WPS setup or restoring network settings.
- Lights: Ready light indicates status (ready, scanning, error, off). Scanner position light indicates straight path mode. Error light indicates an issue.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Product Does Not Turn On or Turns Off Unexpectedly | Power cord is not plugged in. | Plug the power cord firmly into the AC inlet and a working electrical outlet. |
| Scanner Button Does Not Start Scanning | Scanning software is not installed or running correctly. | Ensure Epson Scan 2 or Epson ScanSmart is installed and running. Restart the software. |
| Scanning Software Does Not Operate Correctly | Software conflicts or corruption. | Restart the software. Reinstall the scanning software if problems persist. |
| Cannot Start Epson Scan 2 | Epson Scan 2 is not installed or the installation is corrupted. | Reinstall Epson Scan 2 from the Epson website or the supplied software CD. |
| Paper Feeding Problems | Originals are not loaded correctly in the input tray. | Ensure originals are placed flat and aligned correctly within the edge guides. Do not overload the tray. |
| Paper Jam Problems | Obstruction in the paper path. | Carefully remove the jammed paper following the instructions in the manual. Ensure no foreign objects are in the scanner. |
| Scanning is Slow | High resolution or complex scan settings. | Reduce the scan resolution or simplify scan settings. Ensure your computer meets the system requirements. |
| Cannot Scan Over a Network | Incorrect network settings or connection issues. | Verify Wi-Fi connection. Check network cables if using a wired connection. Restart the scanner and your router. Refer to the Wi-Fi Networking section. |
| Scanned Image Quality Problems (e.g., blurry, distorted, uneven colors) | Dirty scanner glass, incorrect settings, or damaged originals. | Clean the scanner glass. Adjust scan settings (resolution, color). Ensure originals are in good condition. |
| Characters are Not Recognized During Conversion to Editable Text (OCR) | Poor original quality, incorrect language settings, or OCR software issues. | Ensure originals are clear and legible. Select the correct language in the OCR software. Update or reinstall OCR software. |
