Manual for fg4h2272uf

Manual for fg4h2272uf

Brand: FRIGIDAIRE

Category: Refrigerator

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 9:16 p.m.

Manual Publish Date: 2018-08-01

Warranty Information

The appliance is covered by a one-year limited warranty from the original date of purchase for defective parts or workmanship.

This manual covers the operation and care of your Frigidaire refrigerator. It includes safety instructions, installation guidelines, features overview, how to use the display and dispenser, storage tips, cleaning procedures, and troubleshooting. Key operations include setting temperatures, using the ice and water dispenser, and adjusting storage features.

Troubleshooting and error codes

Concern Potential Cause Common Solution
Automatic Ice Maker Ice maker is not making any ice.
  • Ice maker is turned off.
  • Refrigerator is not connected to water line or water valve is not open.
  • The water supply line is kinked.
  • The water filter is not seated properly.
  • The water filter may be clogged with foreign material.
Automatic Ice Maker Ice maker is not making enough ice.
  • Ice maker is producing less ice than expected.
  • The water filter may be clogged with foreign material.
  • The water supply line is kinked.
  • Water pressure is extremely low.
  • Reverse osmosis system is in regenerative phase.
Automatic Ice Maker Ice cubes are freezing together.
  • Ice cubes are not being used frequently enough or interruption of power for prolonged time.
  • The hollow cubes break open in the bin and leak their water onto existing ice, which causes it to freeze together.
Dispenser (Ice & Water) Dispenser will not dispense ice.
  • There is no ice in the bin to be dispensed.
  • The refrigerator doors are not completely closed.
  • Dispenser paddle has been pressed too long and the dispenser motor has overheated.
Dispenser (Ice & Water) Ice dispenser is jammed.
  • Ice has melted and frozen around auger due to infrequent use, temperature fluctuations, and/or power outages.
  • Ice cubes are jammed between ice maker and back of ice container.
Dispenser (Ice & Water) Dispenser will not dispense water.
  • Water filter not seated properly.
  • Water filter is clogged.
  • Household water line valve is not open.
Dispenser (Ice & Water) Water not cold enough.
  • As warmer tap water goes through the filter and enters the water supply system, the chilled water is pushed through to the dispenser. Once the chilled water is used up, it will take several hours to bring the freshly replaced water to a cooler temperature.
Dispenser (Ice & Water) Water has an odd taste and/or odor.
  • Water has not been dispensed for an extended period of time.
  • Unit not properly connected to cold water line.
Opening/Closing Of Doors/Drawers Door(s) will not close.
  • Door was closed too hard, causing other door to open slightly.
  • Refrigerator is not level.
  • Refrigerator is touching a wall or cabinet.
  • Food/packaging is obstructing the door from closing.
  • Flipper mullion on left fresh food door is not in the correct position.
Opening/Closing Of Doors/Drawers Drawers are difficult to move.
  • Food is touching shelf on top or drawer.
  • Track that drawers slide on is dirty.
Running of Refrigerator Compressor does not run.
  • Refrigerator is in defrost cycle.
  • Plug at electrical outlet is disconnected.
  • House fuse blown or tripped circuit breaker.
  • Power outage.
Running of Refrigerator Refrigerator seems to run too much or too long.
  • The variable speed compressor is designed to run 100% of the time except during the defrost cycle.
Digital Temperature Setting Display Digital temperature displays an error.
  • Electronic control system has detected a performance problem.
Water/Moisture/Frost Inside Refrigerator Moisture collects on inside of refrigerator walls.
  • Weather is hot and humid.
  • Flipper mullion
  • Vegetables contain and give off moisture.
Water/Moisture/Frost Inside Refrigerator Water collects on bottom side of drawer cover.
  • It is not unusual to have moisture on the bottom side of the cover.
  • Both crispers contain an automatic humidity control, which should adjust automatically to the varying levels of moisture inside the drawer without creating additional condensation or drying out the air inside the crisper drawer, works with various types of produce.
Water/Moisture/Frost Inside Refrigerator Water collects in bottom of drawer.
  • Washed vegetables and fruit drain while in the drawer.
  • Dry items before putting them in the drawer. Water collecting in bottom of drawer is normal.
Water/Moisture/Frost Outside Refrigerator Moisture collects on outside of refrigerator or between doors.
  • Weather is humid.
Food/Drinks in Fresh Food Compartment/Custom-Flex Drawer Food is freezing.
  • Temperature setting is too low.
  • Temperature sensor is covered by food (right side of fresh food area).
  • Food is covering the air ports.
Food/Drinks in Fresh Food Compartment/Custom-Flex Drawer Drinks are freezing.
  • Temperature setting is too low.
  • Cold drink timer is set too long.
