Brand: Fujifilm
Category: Camera
Document Type:
Language: EN
Manual for FINEPIX REAL 3D V3
Uploaded: Aug. 9, 2025, 11:50 p.m.
Manual Publish Date: 2011-10-01
Warranty Information
Please present the warranty and purchase receipt when requesting repairs.
Viewing 3D Images
For optimal 3D viewing, position yourself directly in front of the screen at a distance of 40-50cm. The viewer uses a lenticular display, eliminating the need for glasses.
Getting Started
Ensure you have read the safety warnings and familiarized yourself with the manual's symbols and conventions. Confirm all package contents are present.
First Steps
Prepare the remote control by removing the insulating sheet from the battery compartment. If needed, replace the battery. Extend and adjust the viewer's stand for comfortable viewing, or mount it on a tripod.
Turning On/Off
Connect the AC power adapter and switch the viewer ON. The viewer will display a welcome screen and then a demonstration slide show. To turn off, slide the power switch to OFF.
Basic Setup
Choose your preferred language and set the correct date and time for calendar and timer functions.
Troubleshooting and error codes
| Problem | Possible cause | Solution |
|---|---|---|
| No pictures are displayed. | The external storage device is not correctly inserted. | Insert the device in the correct orientation. |
| The external storage device or internal memory contains no pictures. | Use a computer, camera, or other device to check that the storage device or internal memory contains pictures. | |
| The pictures have been modified on a computer. | Pictures that have been modified on a computer may not display correctly. | |
| Cannot find picture. | The picture has been modified on a computer. | The viewer may fail to read files that have been modified on a computer. |
| Cannot delete pictures. | Pictures are protected. | Remove protection using a camera (if applicable) or computer. Protection can be removed from the files in internal memory when the viewer is connected to a computer. |
| Computer can not detect internal memory. | The USB cable is not correctly connected. | Check the connection. |
| The computer does not meet the recommended system requirements. | Use a computer that meets the recommended system requirements. | |
| Problem with picture or sound. | The output device is not configured correctly. | Pictures may not be displayed due to improper settings or the inherent limitations of the output device. You may need to adjust HDMI output settings for the device after turning it off and then on again; see the documentation provided with the device for details. |
| The HDMI cable is not correctly connected. | Check the connection. | |
| The cable does not conform to the HDMI standard. | Use a cable that conforms to the HDMI standard. | |
| The HDMI cable does not support high speed. | Use a high-speed cable when viewing 3D images. | |
| Cannot connect cable. | The connector is not in the correct orientation. | Insert the connectors in correct orientation. |
| The connector is not type A. | Use a cable with a type A connector. | |
| 3D display not available. | Side-by-side pictures will not be displayed in 3D if Auto is selected for HDMI Setting. | Select Side by Side. |
| The current HDMI Setting does not match output device. | Choose the appropriate option for HDMI Setting. | |
| The current picture is a 2D image. | 2D images are displayed in 2D. | |
| Remote control has no effect. | The battery is exhausted. | Insert a fresh battery. |
| Clock has been reset. | Power has been interrupted for an extended period. | Connect the AC power adapter and reset the clock. |
