Manual for ETERNUS LT20 S2
Uploaded: Nov. 21, 2025, 6:48 p.m.
Manual Publish Date: 2013-02-01
Warranty Information
The warranty does not apply to failures due to physical abuse, misuse, or unauthorized modifications.
Basic Operation Summary
This manual covers the installation, setup, and operation of the FUJITSU ETERNUS LT20 S2 LTO Library. Key operational aspects include:
- Operator Control Panel (OCP): Used for direct control and monitoring of library functions, including operating modes, power management, and menu navigation.
- Remote Management Unit (RMU): Provides remote access for configuration, status monitoring, and operations such as moving media and running diagnostics.
- Tape Cartridges: Details on using, maintaining, labeling, and write-protecting LTO tape cartridges.
- Magazines: Instructions for inserting and removing tape cartridges from magazines, as well as replacing magazines.
- Connectivity: Supports SAS and Fibre Channel interfaces for integration with host systems.
- Maintenance: Covers basic servicing, including cleaning tape drives and performing diagnostics.
The library is designed for automated data protection in small to medium-sized businesses.
Troubleshooting and error codes
| Section | Description |
|---|---|
| 5.1 Installation Problems | Covers LUN Scanning, Backup Application Installation, and Device Driver Installation issues. |
| 5.2 Troubleshooting Table | A comprehensive table detailing common issues and their solutions. |
| 5.3 Removing Stuck Tapes from Slots | Provides guidance on resolving issues with tapes stuck in slots. |
| 5.4 Magazine Does not Unlock via OCP or RMU | Addresses problems with magazine unlocking mechanisms. |
| 5.5 Media Removal Prevented | Details solutions when media removal is blocked. |
| 5.6 Tape Library Error Codes | Lists and explains error codes generated by the tape library. |
