Warranty Information

Consult the Warranty Booklet for detailed warranty information.

Getting Started

  • Unpack and check the delivery, verify contents against delivery note.
  • Set up the device, ensuring ventilation.
  • Connect cables to the monitor and computer.
  • Switch the device on and off.

Operation

  • Adjust brightness, contrast, and other picture settings using the OSD menu.
  • Select application modes (sRGB, Office, Photo, Video).
  • Adjust volume and audio input.
  • Utilize advanced settings like input selection and factory recall.
  • Display information about the monitor.

Troubleshooting and error codes

Having this problem? Check the following points:
No screen display Power indicator does not light up Check whether the power cable on the monitor is connected correctly. Check whether the computer is switched on.
No screen display Power indicator is lit Check whether the computer is switched on. Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Press any key on the computer keyboard. The computer may be in power saving mode. Alter the brightness and/or contrast until you get a picture.
Message: No Signal Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Check whether the computer is switched on.
Message: Frequency out of range: ## kHz / ## Hz Please change the display mode to 1920 x 1200 with 60 Hz The input signal (horizontal frequency and refresh rate) at the displayed input does not correspond to the technical data for the monitor. Adjust the video frequency range using the computer software (refer to the documentation for the computer or graphics card). Select a valid screen resolution using the computer software (refer to the documentation for the computer or graphics card).
Picture position not correct The monitor recognises an undefined mode (see chapter "Technical specification", Page 35). Press the AUTO button to conduct the auto-adjustment of the screen.
Picture is shaking Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Press the AUTO button to conduct the auto-adjustment of the screen.
Picture is wrongly adjusted Run the Factory Recall function in the OSD menu. The Auto Processing message appears.
Picture disturbances (vertical lines) Press the AUTO button to conduct the auto-adjustment of the screen.
Picture disturbances (horizontal lines, picture noise) Press the AUTO button to conduct the auto-adjustment of the screen.
The screen becomes darker The background lighting has a limited lifetime. If your monitor display should become too dark, the background lighting will have to be replaced. Contact our Service Desk.
