Manual for LCD Monitor

Manual for LCD Monitor

Brand: Fujitsu

Category: Monitors

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:05 p.m.

Manual Publish Date: 2011-01-01

Warranty Information

None

  • Connect the monitor to the computer using the supplied data and power cables.
  • Ensure the computer and monitor are switched off before connecting.
  • Switch on the monitor first, then the computer.
  • Adjust the monitor's rake for optimal viewing.
  • The ON/OFF switch controls the monitor's power.
  • The power indicator shows the monitor's status (green/blue for ON, orange for standby/no signal, off for OFF).

Troubleshooting and error codes

Having this problem? Check the following points:
No screen display (power indicator does not light)
  • Check whether the monitor is switched on.
  • Check whether the power cable on the monitor is connected correctly.
No screen display (power indicator lights)
  • Check whether the computer is switched on.
  • Check whether the data cable for the monitor is correctly attached to the monitor port on the computer.
  • Press any key on the computer keyboard - the computer may be in energy saving mode.
  • Alter the brightness and/or contrast until you get a picture.
Message: No Video Input Or No Signal
  • Check whether the data cable for the monitor is correctly attached to the monitor port on the computer.
  • Check whether the computer is switched on.
Message: e.g. This is 85 Hz overdrive. Change computer display input to X ..... at 60 Hz. or Frequency out of range Please change the display mode to .....
  • The input signal (horizontal frequency and refresh rate) does not correspond to the technical monitor data.
  • Adjust the video frequency range using the computer software (see documentation for your computer or your graphics card).
  • Adjust a different screen resolution using the computer software (see documentation for your computer or your screen controller).
Picture position not correct
  • The monitor recognises an undefined mode.
  • Carry out the auto-adjustment of the monitor (with the AUTO button - if present - or via the OSD menu).
  • Set the picture position with the OSD menu.
Picture is shaking
  • Check whether the data cable for the monitor is correctly attached to the monitor port on the computer.
  • Carry out the auto-adjustment of the monitor (with the AUTO button - if present - or via the OSD menu).
Picture disturbances (vertical lines)
  • Carry out the auto-adjustment of the monitor (with the AUTO button - if present - or via the OSD menu).
Picture disturbances (horizontal lines, picture noise)
  • Carry out the auto-adjustment of the monitor (with the AUTO button - if present - or via the OSD menu).
Picture too light or too dark
  • Carry out the auto-adjustment of the monitor (with the AUTO button - if present - or via the OSD menu).
  • Correctly set the contrast and brightness with the OSD menu if the auto-adjustment function does not supply satisfactory results.
