Warranty Information

Warranty information is provided. Contact sales office or Service Desk for details.

Switching the device on and off

Use the On/Off touch sensor to switch the device on and off. The LED indicator shows the status: blue for normal mode, green for ECO mode, orange when no video signal or in BASIC power saving mode, and off when the monitor is switched off or in 0 W energy-saving mode.

Adjusting Brightness and Contrast

Access the Brightness/Contrast setting window to adjust brightness, contrast, black level, and auto brightness. Auto level adjusts contrast automatically via the touch sensor. Be mindful that excessively high contrast can lead to loss of detail in bright areas.

Selecting Application Mode

Choose from D mode (DICOM simulation), Office presets, Photo presets, or Video presets to optimize settings for different uses. ACR is a dynamic contrast setting.

Adjusting Picture Size and Position

Use the Image adjust setting window to fine-tune the picture by adjusting phase, clock, H-Position, V-Position, sharpness, saturation, and expansion for full screen or aspect ratio preservation.

Adjusting Volume

Control the volume for integrated loudspeakers or mute them using the Audio setting window.

Setting Colour Temperature and Colours

Select color temperature (sRGB, 6500K, 7500K, 9300K, Native, Custom) and adjust color ratios (red, green, blue) for optimal display. sRGB and 6500K are recommended for Windows applications.

Setting Functions

Access the Setup settings window to select the input signal (VGA, DVI, DP, HDMI), set the OSD menu language, activate/deactivate DDC-CI, set OSD timeout duration, and reset settings to factory defaults.

Displaying Information

The Information setting window displays the model designation, serial number, resolution, H/V frequency, and ECO mode.

Troubleshooting and error codes

Having this problem?	Check the following points:
No screen display Power indicator does not light up	Check whether changing the 0 W switch on the rear to setting " I " eliminates the problem. Check whether the power cable on the monitor is connected correctly. Check whether the computer is switched on.
No screen display LEDs not lit	Check if you are using a DP data cable and if the 0 W switch is set to "l".
No screen display Power indicator is lit	Check whether the computer is switched on. Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Press any key on the computer keyboard. The computer may be in power saving mode.
Message: No Signal	Alter the brightness and/or contrast until you get a picture.
Message: Frequency out of range: ## kHz / ## Hz Please change the display mode to 2560 x 1440 with 60 Hz	Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Check whether the computer is switched on. The input signal (horizontal frequency and refresh rate) at the displayed input does not correspond to the technical data for the monitor. Adjust the video frequency range using the computer software (see documentation for the computer or display adapter). Set a different screen resolution using the computer software (see documentation for the computer or display adapter).
Picture position not correct	The monitor recognises an undefined mode (see chapter "Technical specification", Page 31).
Picture is shaking	Touch the AUTO sensor to perform auto-adjustment of the screen. Check whether the data cable for the monitor is correctly attached to the monitor port on the computer. Touch the AUTO sensor to perform auto-adjustment of the screen.
Picture is wrongly adjusted	Run the Factory Recall function in the OSD menu. The Auto Processing message appears.
Picture disturbances (vertical lines)	Touch the AUTO sensor to perform auto-adjustment of the screen.
Picture disturbances (horizontal lines, picture noise)	Touch the AUTO sensor to perform auto-adjustment of the screen.
The screen becomes darker	The background lighting has a limited lifetime. If your monitor display should become too dark, the background lighting will have to be replaced.
For DVI connection: Despite the correct resolution of 2560 x 1440, small fonts are not sharp or are illegible and black font is shown coloured. (The information menu of the monitor shows a resolution of 1280 x 1440).	Contact our Service Desk. Use the DVI - Dual Link data cable which was supplied with the monitor.
