Manual for fi-7300NX
Uploaded: Nov. 21, 2025, 9:05 p.m.
Manual Publish Date: 2018-06-01
Warranty Information
The product comes with a 5-year support period.
Operating the Scanner
The scanner can be operated in two main ways:
- Operating with a Computer: Connect the scanner via USB or network to manage images on your computer.
- Operating with PaperStream NX Manager: Connect the scanner via network to PaperStream NX Manager for image processing, monitoring status, and saving images to a linked destination.
Basic Operations
- Power: Turn the scanner ON/OFF using the power button.
- ADF: Open and close the Automatic Document Feeder (ADF) for loading documents.
- Stacker: Set up the stacker for ejected documents.
- Scanning: Perform scans using scanning applications on the computer or directly from the touch screen.
- Loading Documents: Prepare and load documents into the ADF, considering paper size, type, and weight.
Troubleshooting and error codes
| Issue | Description | Page |
|---|---|---|
| Paper Jam | When a Paper Jam Occurs | 140 |
| Errors | General Errors | 142 |
| Paper Feeding Error | Paper Protection, Paper Jam, Multifeed, Feed Mode Switched | 145 |
| Sensor(s) dirty | Detects dirt on sensors. | 146 |
| Cover Open Error | The cover is open. | 147 |
| Internal and Optical Errors | Optical Error, Operator Panel error, EEPROM Error, Image Memory Read-Write Error | 148 |
| Overrun Error | Background Switching Mechanism Error | 150 |
| Chip Error | Memory Error | 151 |
| Motor Circuit Error | Motor Circuit Error, Lamp Circuit Error | 152 |
| Sensor Error | Sensor Error | 153 |
| Communication Related Errors | Module Error, Network Setting Error, Server Setting Error, Authentication Failed | 154 |
| Other Errors | Being used by others, Doc Counting mode, Scanning paused, Outside designated scan area, Invalid Command | 156 |
| Connection Test Result | Indicates the result of the connection test. | 158 |
| Troubleshooting (General) | Scanner cannot be powered ON, Touch screen issues, Cannot connect via Wi-Fi or LAN, Network not displayed, WPS fails, Wi-Fi connection failure. | 159, 166, 172, 174, 177 |
| Scanning Issues | Connection unstable, Cannot connect to destination, Scanning does not start, Takes a long time, Poor image quality, Distorted images, Vertical streaks, Error code U4:40, Overlapped documents, Document not fed, Paper protection active, Paper jams, Elongated images, Shadows, Black traces, Carrier sheet issues. | 180, 181, 186, 188, 191, 192, 193, 194, 195, 196, 197, 198, 201, 203, 205, 207, 208, 209, 210, 212 |
