Warranty Information
Refer to your local Fujitsu branch or sales staff for specific warranty information.
Overview
This KVM switch allows administrators to access and control multiple servers from a single USB KVM (keyboard, Video, and mouse) console. No software configuration is required.
Features
- Simple plug-and-play installation.
- Single console control for up to 8 (KVM0108A) or 16 (KVM0116A) servers.
- Scalable up to 31 switches, controlling up to 512 servers.
- Hardware independent cross-platform support.
- RJ-45 connectors for Cat 5e/6 cabling.
- Strong password protection and multiple user accounts (up to 10 users + 1 administrator).
- Auto scanning and broadcast mode for monitoring and simultaneous commands.
- Superior video quality with support for high resolutions over distances.
- Hot pluggable for adding or removing components without powering off.
- Server modules with ID for automatic recognition and hot-swap capability.
Troubleshooting and error codes
| Symptom | Action |
|---|---|
| Mouse and/or Keyboard not responding | Unplug the cable from the console port, then plug it back in. |
| All Station IDs display as 01 |
Station 1 suddenly lost power. Wait a few seconds for the system to re-initialize the station sequence and display the proper IDs.
|
