Manual for Dash Cam 30/35

Manual for Dash Cam 30/35

Brand: GARMIN

Category: Automotive Electronics

Document Type: Manual

Language: EN

Uploaded: Aug. 10, 2025, 12:45 a.m.

Manual Publish Date: 2015-10-01

Getting Started

  • Install Memory Card: Insert a microSD card into the slot.
  • Install Mount: Clean windshield, remove protective film from adhesive, press mount firmly for 30 seconds, wait 24 hours for bonding.
  • Setup Dash Cam: Connect power cable, secure mount to arm, plug into vehicle power outlet, follow on-screen instructions.

Dash Camera Recording

  • Record Video: Device starts automatically. Manually save video by pressing the record button.
  • Take Picture: Press the photo button while recording.
  • Event Detection: Device automatically saves footage during collisions.
  • View Media: Access Gallery to view saved videos (Saved Videos, Events, Unsaved Videos) and photos.
  • Connect to Computer: Use USB cable to transfer files.

Forward Collision Warning System (FCWS)

  • Alerts when safe distance is not maintained. Activates above 48 km/h (30 mph).

Device Settings: Adjust brightness, display timeout, setup, about information, and volume.

Troubleshooting and error codes

Problem Solution
My device is in demo mode. 1 Turn off the device.
2 Remove the memory card.
3 Insert memory card into your computer.
4 Delete the DCIM/110DEMO folder.
5 Replace memory card into your camera.
