Brand: GARMIN
Category: Other
Document Type: Manual
Language: EN
Manual for VIRB
Uploaded: Aug. 10, 2025, 12:44 a.m.
Manual Publish Date: 2014-05-01
Warranty Information
Garmin reserves the right to change or improve its products and manual content without prior notice.
Turning On and Off
To turn the device on, hold the power button. To turn it off, hold the power button again. The device can also be turned on and off using the REC switch, which allows for quick recording start and automatic power-off to conserve battery.
Modes
The device operates in several modes: VIEWFINDER (camera view), PLAYBACK (viewing media), DASHBOARD (sensor data, VIRB Elite only), and SETUP (settings). Cycle through modes using the MODE button.
Recording Video
Slide the REC switch toward the lens to start recording video. The device will automatically turn on if it's off. To stop recording, slide REC away from the lens. Videos are saved as MP4 files.
Taking Photos
You can take photos by selecting the capture button in the VIEWFINDER mode, holding the power button, or by selecting the capture icon while recording video.
Connecting to Computer
Connect the device to a computer using the USB cable to transfer files. The device and memory card will appear as removable drives.
Troubleshooting and error codes
| Issue | Solution |
|---|---|
| My device does not turn on | Install a memory card. Verify the battery is installed correctly. Fully charge the battery. |
| My device display is hard to see | The display is reflective and does not have a backlight. Increase ambient light or move to a brighter area. |
| Some information is missing from the dashboards | Enable GPS. Connect ANT+ sensors. Ensure sensors are paired and within range. |
| My video recordings do not look smooth | Enable the Stabilize feature. Use a Class 10 or better microSD memory card. |
| My device turns off when I stop recording video | This is normal behavior if the device was turned on using the REC switch. |
