Camera Setup

  • Voice Control: Use voice commands for hands-free operation.
  • Record Light: Turn the recording indicator on or off.
  • Tone Volume: Adjust the volume for camera tones.
  • Playback Volume: Adjust the volume for video playback.
  • Orientation: Capture correctly oriented video and photos by setting the camera's orientation (Auto, Right Side Up, or Upside Down).
  • Microphone: Enable the internal or external microphone.

Recording Video

  • Use the recording switch to start and stop video recording.
  • Video is saved as .mp4 files, with G-Metrix data saved as .fit files.

Taking Photos

  • Use the camera key or the viewfinder to take photos.
  • Options include Single, Burst, and Time-lapse modes.
  • Time-lapse modes allow capturing series of photos at set time or distance intervals.
  • Delayed photos can be taken using the self-timer.

Playback

  • View photos and videos on the device screen or external display.
  • Filter content by All, Favorites, Videos, or Photos.
  • Mark items as favorites for easy access.
  • Delete photos and videos.

Connectivity

  • Wi-Fi: Set up an access point or connect to existing networks for remote control and data transfer.
  • ANT+: Pair with ANT+ sensors for G-Metrix data.
  • Bluetooth: Connect external microphones or OBD-II devices.

Troubleshooting

  • Covers issues like the camera not turning on, overheating, fogging inside the case, missing G-Metrix data, choppy video, and unexpected shutdowns.
  • Tips for extending battery life are also provided.

Troubleshooting and error codes

Issue Solution
My camera does not turn on
  • If connected to external power, ensure the top status LED is red or off, then hold POWER to turn on.
  • Verify battery installation.
  • Fully charge the battery.
My camera feels warm while it is operating Normal during typical use, especially when recording high-resolution video or transmitting Wi-Fi.
There is fog, mist, or water inside the camera case
  • Fogging is normal in humid environments. Install an anti-fog desiccant pack.
  • If significant water is present, stop use and check the gasket for damage.
Some G-Metrix data is missing
  • Enable GPS, install the altimeter door, and go to an area with a clear sky.
  • Connect compatible ANT+ sensors.
  • Ensure data requires sensor connection.
My video recordings do not look smooth
  • Enable image stabilization (Video > Stabilizer).
  • Use a recommended high-speed memory card.
  • Verify playback device/software compatibility (e.g., 4K resolution).
  • Transfer video to a computer for playback.
  • Use VIRB Edit for playback and editing.
My device turns off when I stop recording video If powered on by the recording switch, it will turn off when the switch is moved back. This conserves battery.
Extending the Battery Life
  • Disable Wi-Fi.
  • Enable Auto Off.
  • Use the recording switch to turn the device on/off.
  • Use automatic recording.
  • Disable ANT+ and Wi-Fi Remote Wake Up when not in use.
  • Reduce screen brightness.
