Warranty Information
This warranty covers manufacturing defects in Australia and New Zealand for 24 months from the purchase date.
Using Your Cooktop
Safety First: Avoid spraying aerosols near the appliance when it's on. Ensure good ventilation, especially in confined spaces. Never use the cooktop as a space heater.
Controls: Each knob controls a specific burner. Refer to the control panel markings and Figure 2 for burner identification and settings (HI, LOW, OFF).
Lighting Burners: Use electronic ignition by depressing and turning the knob to HIGH. If using a push-button ignition model, press the ignition button while turning the knob. If a burner doesn't light within 5 seconds, turn it off, wait for gas to disperse, then try again. Manual ignition with a handheld source is an option if electrical power is out. Always keep hands clear when lighting.
Burner Operation: Operate burners only between 'HIGH' and 'LOW' settings.
Hotplates: Choose the appropriate hotplate size for your cooking needs (small for simmering, medium for normal, large for fast heating, wok burner for woks/large pots).
Pots and Pans: Use common pot materials like aluminum, stainless steel, cast iron, and ceramic. Ensure pots are steady with flat bases. Avoid boiling food too rapidly to save energy.
Utensils: Use appropriately sized utensils for each burner. Never use asbestos mats, wire mats, grids, or aluminum foil, as this can cause damage and void the warranty. Woks should only be used on the wok burner with a wok support trivet.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Burner will not light even though the sparker is working | Gas supply valve turned off. | Turn on gas supply to appliance. |
| Control knob not on | Turn knob on (refer to page 3) | |
| Wrong knob turned. | Ensure the knob you are turning corresponds to the burner you want to light. | |
| Port blockage in ignition area. | Ensure that ports in ignition area are clean and dry. | |
| Ignition electrode wet or dirty. | Dry or clean ignition electrode. | |
| Sparking at wrong point because of incorrectly fitted burner crown. | Ensure that the crown is seated properly so that the spark fires to the receiving point in the burner crown (refer to Figure 1). | |
| Injector is blocked. | Ensure injector is clear of foreign material. | |
| No spark is obtained when control knob is activated | Electricity supply is disconnected or switched off. | Switch on electricity or check fuses. |
| Battery is flat. | Replace battery (refer to page 12) | |
| Polarity wrong on battery. | Reorient battery to correct position (refer to page 12). | |
| Ignition electrode wet or dirty. | Dry or clean ignition electrode. | |
| Flames uneven or tending to lift | Flame ports blocked or wet. | Clean or dry flame ports. |
| Burner cap/crown incorrectly fitted. | Ensure these components are fitted correctly. | |
| Flames not staying on when knob is released | Knob not set between 'HIGH' and 'LOW' | Knob MUST be set between these positions. |
| Low heat, slow cooking | Incorrect cooking pot or pan being used. | Refer to Figure 3 (page 4). |
| Benchtop or knobs overheating | Incorrect cooking pot or pan used. | Refer to Figure 3 (page 4). |
| Pot or pan not located on burner properly. | Ensure pot or pan is centrally located on burner. |
