Brand: GE
Category: Dishwasher
Document Type: Parts/Service
Language: EN
Parts/Service for 2016 Stainless Steel Tub Dishwasher
Uploaded: Nov. 21, 2025, 9:13 p.m.
Manual Publish Date: 2016-04-01
Warranty Information
GE provides a one-year limited warranty covering defects in materials or workmanship, including free labor and in-home service.
- The dishwasher features an advanced wash system for improved cleaning.
- It includes a diverter for alternating spray arms, industry-first bottle wash jets (on some models), and a 3-level wash system.
- Features like a new hinge for easier door removal, a third rack (on some models), Steam Prewash, and a Power Dry Fan enhance functionality.
- The Auto Hot Start function purges cooler water lines if the incoming water is below 80°F.
- Cycle times vary based on selected options, water temperature, and soil level.
- The dryer system uses a dual wattage Calrod Heater for both wash and dry cycles, with heat and air circulation for optimal drying.
Troubleshooting and error codes
| Symptom | Diagnosis | Cure |
|---|---|---|
| Dishwasher is "dead", no LED operation, no button operation or beeping occurs. | CSM (Current Sense Module) is tripped and must be fully diagnosed. | Refer to On the Main Control Board CSM section of this guide. |
| Start button does not respond or makes a triple beep sound, but other buttons work. | The dishwasher may be in demo mode. | To exit demo mode, hold "START" and "HEATED DRY" at the same time for 5 seconds. |
