Warranty Information
Warranty information can be found at products.geappliances.com by searching the model number.
Auto Hot Start
The dishwasher checks water temperature and adds time to heat water to 90°F (main wash) or 105°F (final rinse) if below the target.Cycle Information
Cycle times vary based on options, water temperature, and soil level. Times provided are estimates.Heater Algorithm, Dry Cycle
Details the Calrod heater operation for various dry cycles, including 'Calrod on', 'Calrod Pulse', and 'Calrod off - Cool Down' phases with specific timings.Specifications
Provides electrical specifications for components like the circulation pump, drain pump, heater, thermistor, and pressure switch.Troubleshooting and error codes
| Symptom | Diagnosis | Solution |
|---|---|---|
| Dishwasher is "dead", no LED operation, no button operation or beeping occurs. | Attempt placing the dishwasher in Consumer Error Mode. | The CSM (Current Sense Module) is tripped and must be fully diagnosed. Refer to On the Main Control Board CSM section of this guide. |
| Start button either does not respond or it makes a triple beep sound every time it's pressed AND all other buttons respond as normal. | The dishwasher may be in Demo Mode. | To exit Demo Mode, see the Demo Mode under Electronic Controls in this guide. |
