Warranty Information

1-year limited warranty on parts and labor, with extended warranties on racks, control module, and tub/door liner.

Control Settings

  • Status Indicator Lights: Indicate the current cycle stage (Sensing, Washing, Rinsing, Drying, Sanitized, Clean).
  • Time Remaining Display: Shows estimated minutes until cycle completion.
  • Selections: Choose wash cycles like Anti-Bacteria, Pots & Pans, Normal Wash, Speed Cycle, China Crystal, Glasses, and Rinse Only.
  • Enhancements/Extras: Options include Pre Wash, Heated Dry (On/Off), Lock, Added Heat, and Delay Hours.

Using the Dishwasher

  • Close the door and select cycle/enhancements.
  • Touch START/RESET to begin.
  • For forgotten dishes, open door after water spray stops, add dish, close door.
  • Use approved dishwasher detergents. Adjust amount based on water hardness.
  • Ensure proper loading of upper and lower racks for optimal cleaning.
  • Use rinse agent to prevent spots and film.

Caring for the Dishwasher

  • Clean control panel with a damp cloth; exterior with polish wax.
  • Protect against freezing if left in unheated areas.
  • Check and clean the air gap if drainage is poor.
  • Clean stainless steel panels with specific cleaners.

Troubleshooting and error codes

Error Messages Possible Causes What To Do
START/RESET status indicator light flashing You have pressed the START/RESET pad while the dishwasher is running. This will cancel the cycle. The light will stop flashing after the dishwasher drains (about 90 seconds). Press the START/RESET pad only when you want to restart the dishwasher.
Dishwasher BEEPS once every 30 seconds This is a reminder that your dishwasher door has been left open during operation. It will continue beeping until you close the door. Close and latch the door after opening it mid-cycle.
Problem Problem Problem
Dishes and flatware not clean Low inlet water temperature Make sure inlet water temperature is correct (see page 8). Turn on the hot water faucet nearest the dishwasher, let run until the water temperature stops rising. Then start the dishwasher and turn off the faucet. This insures the entering water is hot.
Water pressure is temporarily low. Turn on a faucet. Is water coming out more slowly than usual? If so, wait until pressure is normal before using your dishwasher.
Air gap or disposer is clogged Clean the air gap or flush the disposer.
Improper rack loading Make sure large dishware does not block the detergent dispenser or the wash arms. See the Loading the dishwasher racks section.
No air gap or high drain loop Verify that you have an air gap or a high drain loop. Refer to the Installation Instructions.
Spots and filming on glasses and flatware Extremely hard water Use Jet-Dry® or Cascade Crystal Clear® rinse agents to remove spots and prevent new film buildup.
Low inlet water temperature To remove stubborn spots and pre-existing film from glassware: 1 Remove all metal utensils from the dishwasher. 2 Do not add detergent. 3 Select the POTS & PANS cycle. 4 Start the dishwasher and allow to run for 18 to 22 minutes. Dishwasher will now be in the main wash. 5 Open the door and pour 2 cups (500 ml) of white vinegar into the bottom of the dishwasher. 6 Close the door and allow to complete the cycle. If vinegar rinse doesn't work: Repeat as above, except use 1/4 cup (60 ml) of citric acid crystals instead of vinegar.
Overloading the dishwasher (See Improper rack loading above)
Improper loading (See Improper rack loading above)
Old or damp powder detergent (See above troubleshooting for detergent)
Rinse agent dispenser empty Check the rinse agent dispenser and fill as required.
Too little detergent (See above troubleshooting for detergent)
Cloudiness on glassware Combination of soft water and too much detergent This is called etching and is permanent. To prevent this from happening, use less detergent if you have soft water. Wash glassware in the shortest cycle that will get them clean.
Water temperature entering the dishwasher exceeds 150°F This could be etching. Lower the water heater temperature.
Suds in the tub Correct detergent wasn't used Use only automatic dishwasher detergents to avoid sudsing. Cascade® and Electrasol® Automatic Dishwashing Detergents have been approved for use in all GE dishwashers.
Rinse agent was spilled To remove suds from the tub, open the dishwasher and let suds dissipate. Close and latch the dishwasher. Pump out water by touching the START/RESET pad once; then 30 seconds later, touch the START/RESET pad again. Repeat if necessary. Always wipe up rinse agent spills immediately.
