Warranty Information

GE will replace any part failing due to defects in materials or workmanship within one year, including labor costs.

1. Power

Press to "wake up" the display. If the display is active, press to turn the dryer off. NOTE: Pressing Power does not disconnect the appliance from the power supply.

2. Dry Cycles

The dry cycle controls the length and tumble speed of the drying process.

  • Normal/Mixed Loads: For loads consisting of cottons and poly-blends.
  • Cottons: For cottons and most linens.
  • Bulky/Bedding: For large coats, bed spreads, mattress covers, sleeping bags, blankets, comforters, jackets, small rugs, and similar large and bulky items.
  • Active Wear: Clothing worn for active sports exercise and some casual wear. Fabrics include new technology finishes and stretch fibers such as Spandex. Also for clothing labeled Easy Care or Perma Press.
  • Delicates: For lingerie and special-care fabrics.
  • Speed Dry: For small loads that are needed in a hurry, such as sports or school uniforms. Can also be used if the previous cycle left some items damp, such as collars or waistbands.
  • Towels/Sheets: Use for towels OR sheets. It is not recommended to mix towels and sheets in the same load.
  • Sanitize: Reduces certain types of bacteria by 99.8%. The antibacterial process occurs when high heat is used.
  • Steam Dewrinkle: Ideal for loads left in dryer for an extended time.
  • Warm Up: Provides 10 minutes of warming time to warm up clothes.
  • Air Fluff: Use to tumble items without heat.
  • Time Dry: Use to set your own dry time.

3. Add Time

Press to add time to specific cycles.

4. Temp

You can change the temperature of your dry cycle.

5. Level

The sensor continuously monitors the amount of moisture in the load.

6. Start/Pause

Press to start a dry cycle. If the dryer is running, press it once and it will pause the dryer. Press it again to resume the dry cycle.

7. My Cycle

Set up your favorite combination of settings and save them here for one touch recall.

8. Steam Refresh

For slightly wrinkled dry garments. Reduces wrinkles on up to 5 garments.

9. Detangle

Activates reverse tumbling to reduce tangling, dry more evenly, and improve drying times.

10. eDry

Reduces the total energy consumption of specific dryer cycles.

Troubleshooting and error codes

SSD Error Name Error Set Condition Error Clear Conditions Error Response Action
000 No Error No Errors No Errors None
001 Inlet Thermistor Short Inlet Thermistor's count of low readings exceeds 10. Inlet Thermistor's count of good readings exceeds 10. Run Heat Control Fallback Algorithm.
002 Outlet Thermistor Short Outlet Thermistor's count of low readings exceeds 10. Outlet Thermistor's count of good readings exceeds 10. Run Heat Control Fallback Algorithm.
003 Inlet Thermistor Open Inlet Thermistor's count of high readings exceeds 10. Inlet Thermistor's count of good readings exceeds 10. Run Heat Control Fallback Algorithm.
004 Outlet Thermistor Open Outlet Thermistor's count of high readings exceeds 10. Outlet Thermistor's count of good readings exceeds 10. Run Heat Control Fallback Algorithm.
005 EEPROM Error Bad CRC Detected when reading a page from EEPROM. Error condition clears when EEPROM checksum is right. None
006 Stuck Button Button depressed for 5 minutes. When the button is released. Cleared when stuck button is released.
007 Miswire L2/N are miswired. Cleared when voltage drops to Normal Levels. L2 and N need to be re-wired.
008 Door Switch Stuck 5 cycles are run and the DOOR_LATCH_SIGNAL goes to open. DOOR_LATCH_SIGNAL goes to open. None
009 Drum Motor Centrifugal Switch does not change within a certain period of time after the Drum Motor relay has been turned on or off. Error condition will not clear until Main Control board sees a change in the centrifugal switch. None
00d Door Signal Stuck 5 cycles are run and the DOOR_STATE signal in the hardware Door Switch Detection Circuit, has not gone open for five cycles. Error condition will not clear until the Main Control Board sees the door switch change. Micro Blackout Recovery to Run will not occur if this error is set, and control will go to pause.
