Installation Guide for NX-320E
Uploaded: Nov. 21, 2025, 6:43 p.m.
Manual Publish Date: 2003-02-01
Warranty Information
Please refer to the GE Interlogix product catalog for warranty details.
The NX-320E is a microprocessor controlled remote power supply module for the NX-8/NX-8E/NX-8-CF control panel. It features three programmable outputs and one dedicated bell output. The module can be added to NetworX control panels to expand output capabilities. It supports features like auxiliary power, smoke detector power, and siren driver power. The module also includes a tamper terminal for enclosure supervision. The total wire run from the control panel to all devices, including the NX-320E, is 2500 feet, and the maximum wire run from the power supply module to outgoing devices is also 2500 feet. It is not recommended to connect multiple power supply modules in series.
Troubleshooting and error codes
| LED | DS1 |
|---|---|
| Description | Flashes when data is transmitted out from the NX-320E. |
| LED | DS2 |
| Description | Flashes when data is transmitted into the NX-320E. |
| LED | DS3 |
| Description | Flashes during normal operation. |
| LED | DS4 |
| Description | Used for hardware, and will only glow dimly when connected to the NX-8/NX-8E/NX-8-CF control panel. |
