Warranty Information

GE provides a one-year limited warranty covering defects in materials and workmanship for the cooktop.

Using The Cooktop

Turning On/Off: Touch and hold the "On/Off" pad for half a second. A chime will sound. To turn off, touch the "On/Off" pad for an individual burner or the "All Off" pad.

Adjusting Power Level: Swipe the gray arc, touch anywhere along the gray arc, or use the "+" or "-" pads. For a shortcut to Hi, touch "+" immediately after turning the unit on. For a shortcut to Low, touch "-" immediately after turning the unit on.

Element Cycling: Surface elements cycle on and off to maintain selected temperature. This is normal and helps prevent overheating.

Adjust Burner Size: Some elements have adjustable ring sizes. Select the ring size by pressing the burner ring graphic.

Synchronize Left Elements: To turn on, hold the "Sync Burners" pad for half a second. Operate either element to adjust power. To turn off, touch the "On/Off" pad on either burner or touch "Sync Burners" to turn both off.

Timers: Use the "Timer Select" pad to set a kitchen timer. The timer does not control the cooking elements.

Lockout: Touch and hold the "Control Lock" pad for 3 seconds to lock or unlock the controls.

Troubleshooting and error codes

Problem	Possible Cause	What To Do
Surface elements will not maintain a rolling boil or cooking is slow	Improper cookware being used.	Use pans that are absolutely flat and match the diameter of the surface unit selected.
Surface elements do not work properly	Cooktop controls improperly set.	Check to be sure the correct control is set for the surface element you are using.
Power arc ON indicator blinking	+, -, or control lock pads have been touched before an element is turned on.	See the Operating the Cooking Elements section.
Scratches on cooktop glass surface	Incorrect cleaning methods being used.	Use recommended cleaning procedures. See the Cleaning the glass cooktop section.
Areas of discoloration on the cooktop	Food spillovers not cleaned before next use. Hot surface on a model with a light-colored glass cooktop.	See the Cleaning the glass cooktop section. This is normal. The surface may appear discolored when it is hot. This is temporary and will disappear as the glass cools.
Plastic melted to the surface	Hot cooktop came into contact with plastic placed on the hot cooktop.	See the Glass surface - potential for permanent damage section in the Cleaning the glass cooktop section.
Pitting (or indentation) of the cooktop	Hot sugar mixture spilled on the cooktop.	Call a qualified technician for replacement.
Unresponsive keypad	Keypad is dirty. A fuse in your home may be blown or the circuit breaker tripped.	Clean the keypad. Replace the fuse or reset the circuit breaker.
