Manual for Reason H49

The Reason H49 is a range of Ethernet switches designed for electrical substations. Key features include:

• Up to 6 1Gbps ports (copper or fiber).
• Support for Parallel Redundancy Protocol (PRP) and High-availability Seamless Redundancy (HSR) protocols.
• PRP and HSR RedBox, HSR QuadBox, and PRP-HSR coupling capabilities.
• Network protocols like SNMP, NTP, and PTP for time synchronization.
• Secure network protocols such as SSH, SFTP, and HTTPS.
• Compliance with various network standards (IEEE 802.1Q, IEEE 802.1p, C37.238) and cyber security standards (NERC CIP, IEEE 1686, IEC 62443).
• Environmental compliance with IEC 61850-3 and IEEE 1613.

Configuration can be done via a web user interface or a command line interface (CLI) using SSH. The device supports various modes including standard switch, PRP RedBox, HSR RedBox, and HSR QuadBox. It also offers features like VLAN management, multicast filtering, priority queuing, and robust security settings including user accounts and authentication. Maintenance involves visual and functional checks, with potential firmware upgrades. The device is designed for vertical mounting on a DIN rail.
