Parts/Service for PGCS1RKZ
Uploaded: Nov. 21, 2025, 8:38 p.m.
Manual Publish Date: 2011-08-01
Warranty Information
GE offers a one-year limited warranty on parts and labor, a thirty-day warranty on water filters, and a five-year warranty on the sealed refrigerating system for Profile models.
- Temperature Controls: Adjust freezer to 0°F and refrigerator to 37°F. Allow 24 hours for stabilization. Display shows both set and actual temperatures.
- Cooling System On/Off: Tap WARMER until display flashes and beeps to turn off. Tap COLDER twice to turn on.
- TurboCool™: Rapidly cools the refrigerator compartment. Activated by pressing the TURBOCOOL pad.
- Door Alarm: Sounds if a door/drawer is open for more than 2 minutes.
- Energy Saver: Turns off the energy saver feature to prevent cabinet moisture.
- Dispenser Light: Turns the night light in the dispenser on/off.
- Dispenser Lock: Prevents accidental dispensing. Press and hold Lock for 3 seconds.
- Showroom Mode: Disables cooling. Enter by pressing temperature pads simultaneously. Exit by unplugging and reconnecting power.
- Defrost Cycle: Adaptive defrost operates between 8-96 hours.
Troubleshooting and error codes
| FZ Display | FF Display | Mode | Comments |
| 0 | 1 | Showroom Mode | Cooling system stops. All HMI functions operate normally. |
| 0 | 2 | Display Combined HMI Software Version | Communications test. Coded software version displayed. Shows "P" for Pass/Fail. |
| 0 | 3 | Display Main Control Software Version | Communications test. Coded software version displayed. Shows "F" if no dispenser board. |
| 0 | 4 | Combined HMI to Main Communications | Communications test. Shows "P" for Pass/Fail, "F" if no dispenser board. |
| 0 | 6 | HMI Self Test | Illuminates LEDs and numerical segments. Toggles LEDs with pad presses. |
| 0 | 7 | Sensor Self Test | Checks thermistors. Displays "P" for pass, "0" for open, or "S" for shorted. |
| 1 | 0 | Open Damper | Damper opens, pauses, then closes. |
| 1 | 1 | Fan Speed Test | Cycles through each fan for 5 seconds. |
| 1 | 2 | 100% Run Time | Runs sealed system 100% of the time for 1 hour. |
| 1 | 3 | Enter Pre-chill | Places freezer in pre-chill mode. Returns to normal operation automatically. |
| 1 | 4 | Toggle the State of Defrost | Toggles the FZ defrost heater status with button presses. |
| 1 | 5 | Refrigerator Reset | Causes a soft reset for Combined HMI and Main board. |
| 1 | 6 | Test Mode Exit | Causes a soft reset for Combined HMI board. Does not terminate main board tests. |
| 1 | 7 | Degree C/F | Sets temperature unit of measure (C or F). |
